304 Stainless Steel Rust Proof Welded Wire Mesh Panel Fence Panel
Stainless steel welded wire mesh is strong and long lasting. By its
very nature stainless steel wire needs no additional finish, such
as galvanizing or PVC, to protect it. The wire itself is extremely
resistant to rust, corrosion and harsh chemicals.
material: SS304,SS3016,SS316L
wire diameter:3mm,4mm,5mm,etc.
aperture:50x50mm,75x75mm,50x100mm,etc.
panel size:2x1m,2.2x1m,2x1.5m,etc.
Welded Wire Fence Panel Features
A. Made of high quality low carbon steel wire.
B. Various colors and sizes.
C. Range of sizes to suit roadway width and bolting patterns.
D. Easy installation
Application
A. Welded wire mesh is widely used in industry and agriculture
building.
B. Egg baskets, pet cages.
C. Runway enclosures.
welded mesh panel introduce as following
| Specification |
| Opening Mesh | Wire Diameter | Width:0.4-2M
Length:5-50m
Material:
*Electric Galvanized before welding
*Electirc Galvanized after welding
*Hot dipped Galvanized before welding
*Hot dipped Galvanized after welding
*PVC-coated
*Stainless steel
SUS304, SUS316, SUS316L,etc.
Packing:
*Each roll packed by water proof paper.
*Each roll shrink wrapped.
Other packing method may be accepted after confirmation. |
| In inch | In metric unit |
| 1/4" x 1/4" | 6.4 x 6.4mm | BWG24-22 |
| 3/8" x 3/8" | 10.6x 10.6mm | BWG22-19 |
| 1/2" x 1/2" | 12.7 x 12.7mm | BWG23-16 |
| 5/8" x 5/8" | 16x 16mm | BWG21-18 |
| 3/4" x 3/4" | 19.1 x 19.1mm | BWG21-16 |
| 1" x 1/2" | 25.4x 12.7mm | BWG21-16 |
| 1-1/2" x 1-1/2" | 38 x 38mm | BWG19-14 |
| 1" x 2" | 25.4 x 50.8mm | BWG16-14 |
| 2" x 2" | 50.8 x 50.8mm | BWG15-12 |
| 2” x 4" | 50.8 x 101.6mm | BWG15-12 |
| 4” x 4" | 101.6 x 101.6mm | BWG15-12 |
| 4” x 6" | 101.6 x 152.4mm | BWG15-12 |
| 6” x 6" | 152.4 x 152.4mm | BWG15-12 |
| 6” x 8" | 152.4 x 203.2mm | BWG14-12 |
