55inch high brightness Digital Advertising Signage double sided
advertising screen
Double Sided Advertising Screen Description
Grab the attention of onlookers with the outward facing, sunlight
readable screen. Once your
customers are inside the building you can then use the inward
facing display to reinforce your
message further.
1. Product highlight: 2500 & 700nit
2. Dual sided design
3. Blackening defect free
4. QWP tech support
5. Auto-dimming light sensor
6. Built-in Android mainboard
Double Sided Advertising Screen Parameter
| Screen Size | 55" |
| Panel Technology | IPS, |
| Aspect Ratio | 16:09 |
| Native Resolution | 1,920 x 1,080 (FHD) |
| Brightness | 2,500 + 700 cd/m2 |
| Contrast Ratio | 1,000:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Surface Treatment | Hard coating (2H), Reflection 1.5% (Typ.) |
| Lifetime | 50,000 Hrs Min. |
| Operation Hours | 24 Hrs |
| Orientation | Portrait |
| OS | Android 7.1 |
| CPU | Rockchip RK3288, 4-core ARM Cortex A17 clocked at 1.6GHz |
| GPU | 4-core ARM Mali-T764 |
| RAM | DDR3 2GB (Optional 4GB) |
| Storage | eMMC 8GB (Optional 32GB), Note: Support TF / USB expansion |
| Input | HDMI, RJ45, VGA, USBx2, Audio |
| Output | / |
| External Control | CMS |
| Bezel Color | Black |
| Bezel Width | 25.0 mm (T/B), 25.0 mm (L/R) |
| Monitor Dimension (W x H x D) | 1315.0*734.0*80.0 mm |
| Weight (Include Ceiling Bracket) | 42.0 kg |
| Carton Dimensions (W x H x D) | 1470 x 900 x 230 mm |
| Packed Weight | 54 kg |
| VESATM Standard Mount Interface | See Drawing |
| Operation Temperature | 0°C to 45°C |
| Operation Humidity | 10% to 80% |
| Power Type | Built-In Power |
| Power Supply | 100-240 V~, 50/60 Hz |
| Power Consumption | Typ. / Max. | 280 W / 310 W |
| Smart Energy Saving | / |
| Safety | / |
| EMC | FCC Class "A" / CE |
| Optional | Stand Mounts Bracket |
| Basic | Remote control(w/o battery), AC power plug, Ceiling Mounts |
| WARRANTY | 18Month, Free spare parts, Technical support |
Double Sided Advertising Screen Drawing
Double Sided Advertising Screen Scenario
With the sunlight readable brightness, roof hanging or floor
standing design, the double sided advertising screen is suitable
for every storefront shop window applicaitons. Such as:
1. Banks, Financial institutions
2. Museum, Public places
3. Retail, Commercial institutions
4. Pharmacy, Medical places
5. Airport, Transportation place
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in double sided
advertising lcd screen LCD
panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or
18months(Non-artificial damages) from
the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available
based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto
dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional
interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board
optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function,
IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each display will
pass through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity, ISO certification, FCC
certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black
over 105 or 110℃.
7.Q: What is the MOQ?
A: Double sided lcd screen Sample testing is acceptable, the price
is negotiable for bulk order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk
order shipped within 2 weeks.
