A Brief Introduction to Heavy Copper PCBs:
There is no specific definition for a heavy copper PCB. However,
the term is more commonly used for PCBs featuring 3 ounces of
copper in the internal and external layers. This term is also
applied to any circuit with copper thickness more than 4 Oz/ft2.
The term extreme heavy copper PCB refers to PCBs with 20 Oz/ ft2
to, which has 200 oz. per ft2 copper deposition on its internal and
external layers.
The copper weight combined with an appropriate substrate and
thicker plating in the through-hole circuit makes these PCBs a
reliable wiring platform. These boards are manufactured through a
variety of etching and plating techniques. The goal is always
adding copper thickness via plated holes and sidewalls.
Heavy copper printed circuit boards feature 3 ounces of copper in
outer/inner layers. These printed circuit boards are valued
immensely, due to their thermal management capabilities. The heavy
copper composition helps keep inner components cool, and improves
their performance.
Place of Origin | Guangdong, China |
Base Material | Copper |
Min. Line Width | 3mil |
Brand Namey | YiZhuo |
Copper Thickness | 1 Oz |
Board Thickness | 1.6mm |
Min. Line Spacing | 3 Mil (0.075 Mm) |
Surface Finishing | HASL Lead Free |
Min. Hole Size | 0.10mm |
sample | welcome |
Testing Service | Function Test |
Solder masks color | Green,black,blue,red, white |
Product name | PCB Board Assembly |
Type | Electronic Board |
ODM | yes |
Custom logo | yes |
Applications of Heavy Copper PCBs:
Heavy copper PCBs are used in the following applications:
- Solar Power Converters
- Torque Controls
- Safety and Signal Systems
- Power Line Monitors
- UPS Systems
- Rail Traction Systems
- Protection Relays
- Storage Pumping Plants
- Overload Relays
- HVAC Systems
Shenzhen Yizhuo Electronics Co., Ltd. is a national high-tech enterprise certified by ISO9001: 2015
international quality management system. It was founded in 2012 and
has been committed to the innovation and sustainable development of
electronic technology. It is used in the manufacture and sales of
various metal PCBs, LEDs and related products. The products are
widely used in lighting, electronics, machinery, communications,
automotive and other industries that require heat dissipation. With
a senior management team and R & D design team with an average
industry experience of more than 8 years, we have created a strong
worldwide distribution network and sales channels, and our products
sell well in Asia-Pacific, Europe, America, and the Middle East.
FAQ:
Q1. What data is required for the quotation?
A: Production requirements, materials (material thickness, copper
thickness), production materials (Gerber files,), quantity
Q2. What service do you have?
A: We can provide one-stop services from PCB manufacturing to PCB
assembly, testing, housing and other value-added services.
Q3. How do I get samples and check your quality?
A: Yes, We Can Send You Our Sample To Check Our Quality
