| | Haval H9 2022 model 2.0T gasoline four-wheel drive exclusive 5-seater version | Haval H9 2022 model 2.0T gasoline four-wheel drive premium model 7-seater version |
| Basic configuration |
| Car class | medium and large suv | medium and large suv |
| Energy Type | Gasoline | Gasoline |
| Market issue time | september.2021 | september.2021 |
| Max power(kw) | 165 | 165 |
| Max torch(Nm) | 385 | 385 |
| Engine | 2.0T 224HP L4 | 2.0T 224HP L4 |
| gearbox | 8 AT | 8 AT |
| L*W*H(mm) | 4843*1926*1900 | 4843*1926*1900 |
| Body structure | 5 door 5 seat SUV | 5 door 7 seat SUV |
| Maximum speed (km/h) | 170 | 170 |
| Official 0-100km/h acceleration (s) | - | - |
| NEDC comprehensive fuel consumption (L/100KM) | 9.9 | 9.9 |
| WLTC comprehensive fuel consumption (L/100KM) | 10.4 | 10.4 |
| Car Body |
| Longth(mm) | 4843 | 4843 |
| width(mm) | 1926 | 1926 |
| height(mm) | 1900 | 1900 |
| wheel base(mm) | 2800 | 2800 |
| front wheel base(mm) | 1610 | 1610 |
| rear wheel base(mm) | 1610 | 1610 |
| approach angle (°) | 28 | 28 |
| departure angle (°) | 23 | 23 |
| Minimum turning radius (m) | | |
| Car Structure | suv | suv |
| door opening method | flat open | flat open |
| Number of doors (PC) | 5 | 5 |
| Number of seats (PC) | 5 | 7 |
| Fuel tank volume (L) | 80 | 80 |
| Trunk volume (L) | - | - |
| Curb weight (KG) | 2285 | 2315 |
| Maximum full load mass (KG) | 2950 | 2950 |
| Engine |
| engine model | GW4C20B | GW4C20B |
| Displacement (mL) | 1967 | 1967 |
| Displacement (L) | 2.0L | 2.0L |
| Intake form | Turbo charged | Turbo charged |
| engine layout | Transverse | Transverse |
| Cylinder arrangement | L | L |
| Number of cylinders (pcs) | 4 | 4 |
| Valves per cylinder (PC) | 4 | 4 |
| Air distribution structure | DOHC | DOHC |
| Maximum horsepower (Ps) | 224 | 224 |
| Maximum power (KW) | 165 | 165 |
| Maximum power speed (rpm) | 5500 | 5500 |
| Maximum torque (NM) | 385 | 385 |
| Maximum torque speed (rpm) | 1800-3600 | 1800-3600 |
| Maximum Net Power (kW) | 160 | 160 |
| fuel form | gasoline | gasoline |
| fuel label | 92 | 92 |
| Oil supply method | direct injection | direct injection |
| cylinder head material | Aluminum alloy | Aluminum alloy |
| Cylinder material | Iron | Iron |
| Environmental Standards | China VI | China VI |
| Transmission |
| Number of gears | 8 | 8 |
| Transmission type | 8 AT | 8 AT |
| short name | 8-speed automatic | 8-speed automatic |
| Chassis steering |
| drive mode | Front wheel drive | Front wheel drive |
| Four-wheel drive | | |
| center differential structure | | |
| Front suspension type | Macpherson independent suspension | Macpherson independent suspension |
| rear suspension type | Multi-link independent suspension | Multi-link independent suspension |
| boost type | Electric assist | Electric assist |
| Body structure | load bearing | load bearing |
| wheel braking |
| Front brake type | ventilated disc | ventilated disc |
| rear brake type | Disc | Disc |
| Parking brake type | Electronic parking | Electronic parking |
| Front tire specification | 265/60/R18 | 265/60/R18 |
| rear tire specification | 265/60/R18 | 265/60/R18 |
| Spare tire specification | Non-full size | Non-full size |
| Active/passive safety equipment |
| Main/passenger airbags | Driver● /Vice driver ● | Driver● /Vice driver ● |
| Front/rear side airbags | Front● /Rear - | Front● /Rear - |
| Front/rear head airbags (curtain) | Driver● /Vice driver ● | Driver● /Vice driver ● |
| Knee airbag | - | - |
| pedestrain auto protect | - | - |
| Tire pressure monitoring function | Tire pressure alarm | Tire pressure show |
| Seat belt reminder | Front● | Front● |
| ISOFIX child seat interface | ● | ● |
| ABS anti-lock | ● | ● |
| Brake force distribution (EBD/CBC) | ● | ● |
| Brake Assist (EBA/BAS/BA) | ● | ● |
| Traction Control(ASR/TCS/TRC) | ● | ● |
| Car steadiness control (ESC/ESP/DSC) | ● | ● |
| Parallel Auxiliary | ○ | ● |
| Lane Departure Warning System | ● | ● |
| Lane Keeping Assist | ● | ● |
| Lane centered keeping | ● | ● |
| Active Braking/Active Safety System | ● | ● |
| Fatigue driving alarm | ● | ● |
| Forward Collision Warning | ● | ● |
| Assist/Control configuration |
| Front/rear parking radar | Front● /Rear ● | Front● /Rear ● |
| driving assistance video | ●360 panoramic image | ●360 panoramic image |
| Reversing side warning system | - | - |
| cruise system | ●adaptive cruise | ●adaptive cruise |
| Driving mode switching | ●sports
●economy
●standard/comfort
●the snow
●off-road | ●sports
●economy
●standard/comfort
●the snow
●off-road |
| automatic parking | ○ | ● |
| Engine start-stop technology | ● | ● |
| automatic hold | ● | ● |
| hill assist | ● | ● |
| steep descent | ● | ● |
| Changable suspension | - | - |
| air suspension | - | - |
| Low-speed four-wheel drive | ● | ● |
| creep mode | ● | ● |
| tank turn | ● | ● |
| Assisted driving level | - | - |
| External / Anti-Theft Configuration |
| sunroof type | ●Openable panoramic sunroof | ●Openable panoramic sunroof |
| Sport Appearance Kit | - | - |
| Rim material | Aluminum Alloy | Aluminum Alloy |
| Electrical sunction door | - | - |
| Side sliding door | | |
| Electric trunk | - | - |
| Sense tailgate | - | - |
| Electric trunk position memory | - | - |
| roof rack | ● | ● |
| Engine electronic immobilizer | ● | ● |
| interior central lock | ● | ● |
| key type | Remote Key | ●Remote Key
○Bluetooth Key |
| keyless start system | ● | ● |
| Keyless entry function | ●Front | ●Front |
| Internal configuration |
| Steering wheel material | ●Genuine Leather | ●Genuine Leather |
| Steering wheel position adjustment | ● Manual up and down ● front and rear adjustment | ● Manual up and down ● front and rear adjustment |
| Shift form | ●electric shift | ●electric shift |
| Multifunction steering wheel | ● | ● |
| steering wheel shift | ● | ● |
| Steering wheel heating | ● | ● |
| Trip computer display screen | ●Colorful | ●Colorful |
| Full LCD Dashboard | - | - |
| LCD meter size | ●7'' | ●7'' |
| HUD | - | - |
| built in recorder | ● | ● |
| auto reduce noise | - | - |
| wireless charger | - | - |
| Seat configuration |
| seat material | ○Genuine Leather
●artificial leather | ●artificial leather |
| Sports style seat | - | - |
| main seat adjustment | ●leg rest
●front and rear adjustment
●Backrest adjustment
●lumbar support (2-way)
●Height adjustment (4-way) | ●leg rest
●front and rear adjustment
●Backrest adjustment
●lumbar support (2-way)
●Height adjustment (4-way) |
| Assistant seat adjustment | ●leg rest
●front and rear adjustment
●Backrest adjustment
○Height adjustment (2-way) | ●leg rest
●front and rear adjustment
●Backrest adjustment
●Height adjustment (2-way) |
| Main/passenger seat electric adjustment | Driver● /Vice driver ● | Driver● /Vice driver ● |
| front seat function | ●heating
●ventilation
●massage | ●heating
●ventilation
●massage |
| E seats memory function | Driver● | Driver● |
| Rear boss button | - | - |
| Second row seat adjustment | ●Backrest adjustment | ●front and rear adjustment
●Backrest adjustment |
| 2nd row seats E-adjust | - | - |
| 2nd row seats function | ●heating
●ventilation | ●heating |
| 2nd row seats independent seats | - | - |
| Seats lay out | | 2-3-2 |
| rear seats put down form | Proportionally | Proportionally |
| Front/rear center armrest | Front● /Rear ● | Front● /Rear ● |
| rear cup holder | ● | ● |
| Multimedia configuration |
| Central control color screen | ●Touch LCD screen | ●Touch LCD screen |
| Central control screen size | ●12.3'' | ●12.3'' |
| GPS | ● | ○ |
| Bluetooth phone | ● | ● |
| Phone connect/mapping | ● | ● |
| voice recognition system | ● | ● |
| car internet | - | ○ |
| 4G/5G OTA WIFI | ●4G | ●4G |
| Multimedia/charging interface | ●USB | ●USB |
| Number of USB Type-C ports | Front 2/ rear 1 | Front 2/ rear 1 |
| Luggage compartment 12V power interface | ● | ● |
| Speaker Brand | infinity | infinity |
| Speaker Qty | ●10 | ●10 |
| phone APP remote control | - | - |
| Lighting configuration |
| low beam light source | ●LED | ●LED |
| high beam light source | ●LED | ●LED |
| Lighting Features | Matrix | Matrix |
| LED daytime running lights | ● | ● |
| Auto adaptive high low light | ● | ● |
| automatic headlights | ● | ● |
| Turning Assist light | ● | ● |
| Turning headlight | - | - |
| Headlight rain and fog mode | ●LED | ●LED |
| Headlight height adjustable | ● | ● |
| headlight cleaning device | - | - |
| Headlights delay turn off | ● | ● |
| touch reading light | - | - |
| In-car ambient lighting | 3 colors | 3 colors |
| Glass/Rearview mirror |
| Front/rear power windows | Front● /Rear ● | Front● /Rear ● |
| One window lift function | ● whole car | ● whole car |
| Window anti-pinch function | ● | ● |
| Exterior mirror function | ●Electric adjustment
●mirror heating
●mirror memory
●mirror heating
●Automatic downturn when reversing
●Automatic folding when locking the car | ●Electric adjustment
●mirror heating
●mirror memory
●mirror heating
●Automatic downturn when reversing
●Automatic folding when locking the car |
| Inside rearview mirror function | ●Auto anti-dazzle | ●Auto anti-dazzle |
| Rear sunshade curtain | - | - |
| Rear privacy window | ● | ● |
| interior vanity mirror | ● Front with light●Vice driver | ● Front with light●Vice driver |
| rear wiper | ● | ● |
| Sensor wiper function | rain sensor | rain sensor |
| Air conditioner/refrigerator |
| Air conditioner temperature control method | ●automatic AC | ●automatic AC |
| Rear independent air conditioner | ● | ● |
| rear air outlet | ● | ● |
| temperature zone control | ● | ● |
| car air purifier | ● | ● |
| PM2.5 filter | ● | ● |
