auto double sleeve diagonal labeling machine for boxes with printer
detection kit box label machine
Main Feature
1. It can be used for single and diagonal labeling of flat boxes
and square boxes of different specifications. (It can be connected
by the cartoning machine),It has stable feeding and large buffer
space.
2. Synchronous chain proofreading mechanism, to ensure stable and
accurate proofreading.
3. Screw adjustment system structure, labeling accurate. Large
adjustment range. The box can be adapted to a variety of
specifications.
4. The transparent label does not bubble, the label does not
wrinkle.
Workflow
Single row horizontal horizontal lying position feeding -- feeding
-- conveying -- synchronous top belt clamping --2 labels are pasted
to both sides of the surface/lower position (half upright
suspended) -- double side caress mark -- both sides to the
top/bottom side corner caress mark -- single row horizontal lying
position discharging
The boxes are arranged horizontally. Before labeling, the spacing
required for labeling and caressing is separated by the feeding
wheel, and then it is clamped by the main conveyor belt and
synchronous top belt. When arriving at the labelling station,
trigger the measuring electric eye and trigger the labelling head
to attach the label to the end face (side) of the box. Then, under
the clamping operation of the top belt and the main conveyor belt,
the two suspended parts of the label are respectively pressed to
the top and bottom of the box through the corner caressing the
label.
It can realize 3 sides sealing on one side of the packing box and
diagonal sealing on both sides.
The labeling head adopts our high-precision and large-capacity
labeling head, which is driven and controlled by servo motor, and
can obtain ±1mm stop labeling accuracy and stable linear speed of
100m/min. The label coil (rewinding) capacity is
800m.
The whole machine is controlled by PLC, the Chinese interface touch
screen operation interface, all the electronic control parameters,
operation parameters, status, count can be set on the touch screen
and right storage of more than 50 groups of formula, formula
parameters can be directly called.
When changing labels of different lengths, there is no need to
adjust the position of the electric eye of the label. It is only
necessary to set or call the corresponding stop position on the
touch screen.
Backing paper:
Self-adhesive label parameters 62g white Glassine base paper is
required. The paper is compact and has good internal strength and
transmittance, firm and not easy to be used by Tear. Excellent die
cutting performance
Self-adhesive label parameters
| Basic gram weight | 62g/㎡ ± 5% |
| Thickness | 55μm ± 5% |
| Machine Direction | 16kg/25mm |
| Horizontal | 7kg/25mm |
| Machine Direction | 25g/sheet |
| Horizontal | 31g/sheet |
| Transparency | 52% |
| Label Spacing | 3-4 mm ± 0. 2mm |
