    Winding 0.06mm Self Bonding Wire Enameled Copper

    Ask Lasest Price
    Brand Name : Ruiyuan
    Model Number : 0.06mm
    Certification : UL/ISO9001/ISO14001/RoHS/Reach
    Price : Negotiation
    Payment Terms : Negotiation
    Supply Ability : 10Ton/week
    Delivery Time : 2-15 days
    • Product Details
    • Company Profile

    Winding 0.06mm Self Bonding Wire Enameled Copper

    0.06mm Hot Wind Self Bonding Enameled Copper Wire


    Super thin self bonding enameled copper wire is our superior product, polyurethane insulation film, temperature resistance grades are 155 degrees and 180 degrees. The self-adhesive method is hot air. Color can be customized.


    CharacteristicsTechnical requestsTest ResultsConclusion
    Sample 1Sample 2Sample 3
    1SurfaceGoodOKOKOKOK
    2Bare Wire Diameter0.060±0.0020.0600.0600.060OK
    Bonding film thcinessMin.0.003mm0.0040.0040.004OK
    3Coating Thickness≥ 0.007 mm0.01100.01000.0110OK
    4Overall Diameter≤ 0.077 mm0.07530.07530.0754OK
    5Conductor Resistance5.995-6.306 Ω/m6.166.166.17OK
    6Elongation≥ 17 %242525OK
    7Breakdown Voltage≥ 700VMin.1526OK
    8Bonidng strengthMin. 8g15OK
    Remarik:
    Test ItemsTechnical RequestsResults

    Conclusion:

    Approved

    1AdhesiveCoating layer is goodOK
    2Cut-through200℃ 2minsno breakdownOK
    3Heat Shock390±5℃ 2 min no crackOKAudit byTested by
