Custom PCBA Manufacturer Electronic PCB SMT/DIP Assembly
Product introduction:
Power:3W/5W/7W/9W/12W/15W/18W
Voltage:AC220V
Color Temperature:Warm White 2800K-3200K,Cold White 6000K-6500K
Beam Angle:170 Degree
Housing Material:Aluminum
Life Span:5000hrs
Application:Downlight,ceiling light,DIY
Feature:Don't need driver,connect AC220V directly,easy to install,
support AC180-240V
Model Number: | ZYX-217NNKL | Place of Origin: | Shenzhen, China |
Base Material: | FR-4, RF4 | Brand Name: | BQZYX+ |
Copper Thickness: | 1-4oz, 1-4oz | Min. Line Width: | 0.1mm, 0.1mm |
Board Thickness: | 1.6mm, 1.6mm | Min. Line Spacing: | 0.1mm, 0.1mm |
Min. Hole Size: | 0.1mm | Surface Finishing: | lead free, HASL /Lead free |
ZYX is a high-quality provider of electronics manufacturing
services (EMS) locate in in Shenzhen,China. We serve customers
worldwide along the whole industry chain including product design,
material sourcing, PCBA production, cable assembly, box build
assembly and comprehensive testing services. Our 4,000 sqm
facilities include 6 surface-mount technology (SMT) production
lines, 2 through hole technology (THT) lines , 2 function testing
lines and 2 box build production lines
| Normal FR4,Normal Tg FR4(Halogen free),High Tg FR4(Halogen
free),HDI PCB material |
| Rigid pcb(Backplane,HDI,High multi-layer blind&buried
PCB,Embedded Capacitance) |
| Blind&buried via type,HDI PCB |
| Lead free,Leaded,aspect ratio,Max finished size,MIN finished size,
PCB thickness, MAX high to gold finger |
| External Layer,Width tolerance |
Plating/coating thickness | Tin thickness,OSP, ENIG, Immersion Silver,Immersion Tin,Hard gold,
Soft gold |
| MAX thickness of mechanical hole 4mil/6mil/8mil,Min/Max laser
drilling size,Finshed mechanical hole size |
| Min Pad size for laser drillings,Min Pad size for mechanical
drillings,Min BGA pad size,Pad size tolerance(BGA) |
| MAX drilling tool size for via filled with Soldermask (single side) |
| Min gap between mechanical hole wall and conductor (Local mixed
pressure area) |
| Layer counts,PCB size (Finished),MAX PCB size(Ceramic-substrate
PCB),PCB thickness(Finished) |
| Min space of the V-CUT does not reveal the copper ( Central Line of
v-cut to internal/external circuits,H means board thickness) |
Q. What service can you supply ?
ZYX are OEM PCB and PCBA manufacturer since 2010 ,we can provide
turnkey solutionincluding RD PCB fabrication,SMT and assembly PCBA
inside the enclosure,Functiontesting and other value-added service.
Q. What file you need to prepare if you want to get an quotation
from us?
For PCB board, you need to prepare files of Gerber file,it should
including RS-274X,ODB++, DXF, PCB, PCBDOC etc formats.
For PCBA(PCB with soldered components), except the file for PCB,
you also need to prepare the BOM list (components list), Pick and
Place file(txt format), real sample pictureor 3D PDF version file
etc.
Q. Do you have any MOQ Limited ?
We havent any limited about MOQ .Sample and mass production all can
support.
Q. How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and
promising tokeep customers data in high confidential level.
Q. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the
components
quantity,if simple, within 6 hours can finished,once complex and
more,the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small
batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will
priority to deal it and do ourbest to give you satisfied delivery
time.
Q. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the
function test.Before that, our inspectors will use microscope and
X-ray to check the IC footwelding or bad solder etc.
