Jekit 6 pot brake kit customized bell with 355*32mm disc kit for
front wheel
Things to know before modifying the brakes
1. Thermal decay: The temperature of the brake pads will rise after
the brake system of the car
is used for a certain number of times. After reaching a certain
working condition temperature, the
braking effect of the brake system will reach the best, but the
maximum limit is exceeded The
temperature, which causes the braking force to drop, eventually
disappears completely. This is the
thermal attenuation of the brake.
2. Friction area: The friction coefficient refers to the ratio of
the friction force between two surfaces
and the vertical force acting on one surface. When the brake pedal
is stepped on, the piston in the
caliper will be pushed to generate pressure in the brake oil
circuit. The pressure is transmitted to the
caliper piston via the brake fluid, pushing the brake pads to
tighten the brake disc, and the brake disc
is forced to slow down through friction Rotate.
How to choose the right brake kit
Model selection: The larger the brake kit, the better. It is
unscientific to simply pursue fullness. Each
brake has a brake master cylinder. If the output pressure of the
brake master cylinder fails to reach the
mechanical performance of the caliper. So before buying brakes, you
must understand whether the
brake accessories match.
Chassis number selection: Although the model of the same model is
the same, the difference of the
chassis number will cause the value of the center circle of Yang
Jiao to be different.
Matching the wheel hub: Because the size, shape, J value, ET value
and X value of the wheel hub will
affect the installation space of the brake caliper, so if you want
to modify the brake, you must pay great
attention to the match of the wheel hub, and this point is not very
intuitive to refer to. Data standards
require specific installation and testing.
Type selection: The general modified brakes are divided into racing
version and street version. If it is only
for daily driving, it is recommended to choose the street version.
How the brakes work
The current small cars basically use hydraulic braking, because the
liquid cannot be compressed and can
transmit almost 100% of the power. The basic principle is that the
driver steps on the brake pedal to apply
pressure to the brake oil in the brake master cylinder, and the
liquid will The pressure is transmitted to the
piston of the brake caliper of each wheel through the pipeline, and
the piston drives the brake caliper to
clamp the brake disc to generate huge friction to slow the vehicle.
Product introduction form
Product name | 6 pot brake kit |
| Style | Blade type bell |
| Product material | Aluminum Caliper Bell Bracket .Grey Cast Iron Ht250 Disc. Carbon
Metal Pads |
| Full set included | 1 pair brake caliper/1 pair brake disc with center cap and bracket/ 1 pair brake line/1 set brake pads |
| for wheel size | 19'' |
| functional characteristics | vortex in the form of rapid cooling ,improve 40% of the braking
effect and brake friction performance. |
