DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager

    Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers

    Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers
    • Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers
    • Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers
    • Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers
    • Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers
    • Buy cheap DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager from wholesalers

    DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager

    Ask Lasest Price
    Brand Name : TCS
    Model Number : JQF2236 series5
    Certification : ISO9001、ISO14001、ROHS、REACH
    Price : negotiate
    Payment Terms : T/T
    Supply Ability : 100000+pcs per month
    Delivery Time : 20-25 days
    • Product Details
    • Company Profile

    DC 24V Small Air Solenoid Valve Electric 3 Way 2 Position For Massager

    Micro Mini Electric DC 24V 3-Way 2-Position Small Air Solenoid Valve

    Quick Detail:

    Model Number: JQF2236 series5

    Warranty: 1 year

    Type: Air Valves

    Place of Origin: China

    Application: General, Massager, Massager armchair, Airbed

    Power type: Electric, 2.88*3W

    Structure: Normal open or Normal close, Two positions, Three ways

    Voltage range: DC21.6-26.4V

    Rated voltage: DC24V

    Current: 120*4mA

    Insulation class: A

    Description:

    This is a more special valve, it is a four-link valve, in the massage industry equipment is widely used, and can also be used in medical and other industries. The construction uses Normal open, normal close (all available), Two positions, Three ways. The voltage range is DC21.6-26.4V. The maximum pressure bearing value is 300mmHg.

    Specification:
    item
    value
    Warranty
    1 year
    Type
    Air Valves & Vents
    Customized support
    OEM, ODM, OBM
    Place of Origin
    China
    Guangdong
    Brand Name
    TCS
    Model Number
    JQF2236 series5
    Application
    General
    Temperature of Media
    Normal Temperature
    Power
    Electric
    Media
    Gas
    Structure
    Control
    Application
    Massager, Massager armchair, Airbed
    Brand
    TCS
    Voltage range
    21.6-26.4
    Rated voltage
    24V
    Power
    2.88*4W
    Current
    120*4mA
    Insulation class
    A
    Structure
    N/O, N/C, TWO position, Three ways
    Max pressure
    300mmHg
    Application:
    DC 5V 2 Ways Electric Miniature Air Solenoid Valve Normally Closed 1

    FAQ:

    Q1. Can I have a sample order for solenoid valves?

    A: Yes, we welcome sample order to test and check quality.

    Q2. What about the lead time?

    A: 3-5 days for Sample preparing ,20-25working days for mass production.

    Q3. Do you have any MOQ limit for solenoid valves order?

    A: Yes,1000pcs MOQ, 1-10pcs for sample checking is available.

    Q4. How do you ship the goods and how long does it take to arrive?

    A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.

    Q5. How to proceed an order for solenoid valves?

    A: Firstly let us know your requirements or application.

    Secondly We quote according to your requirements or our suggestions.

    Thirdly customer confirms the samples and places deposit for formal order.

    Fourthly We arrange the production.

    Q6. What are the terms of trade?

    A: FOB, EXW

    Q7: Do you offer guarantee for the products?

    A: Yes, we offer 1 years warranty to our products.

    Q8: How to deal with the faulty?

    A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

    Secondly, during the guarantee period, we will send new air pump with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
