Mini FAKRA Connector Black Color A Code For PCB/Panel Mount
Product description:
HFM complies with all common automotive standards. For frequencies
up to 20 GHz, the smart module system ensures fast transmission of
high data rates of up to 28 Gbps. Compared to conventional FAKRA
connectors, the HFM connector system saves up to 80% of space and
can accommodate a wide range of modules in the smallest of spaces.
Main Feature:
1. Small size - optimal use of space
2. Highest mechanical robustness
3. Modular system - up to 80% saving of installation space
4. Cost optimization
5. Real-time data transmission
6. is not subject to misuse due to the security coding system
7. MOQ:20PCS.
Applications:
1.Autonomous driving
2.Driving assistance system
3.Navigation
4.Infotainment system
5.Rear seat entertainment
6.Internet
Offer Custom:
We accept OEM and ODM orders. If you need a different installation,
please let us know the type of FAKRA connector required, and the
length of the cable, and we will be happy to consider your request
for a working solution. Feel free to contact us.
Technical Specifications:
| FAKRA |
Electrical Data | lmpedance | 50 Ω |
| Frequency range (depends on cable), connector, assembling, testing | DC up to 6 GHz |
| Return loss | ≥ 18 dB |
| Insulation resistance | ≥1x 1 GΩ |
| Center contact resistance | ≤5mΩ |
| Outer contact resistance | ≤5mΩ |
| Test voltage | 750V DC |
| Working voltage | 60V DC |
| Contact current (depending on cable size, connector and housing) | ≤4A DC |
| RF-leakage | ≥65 dB |
Mechanical Data | Mating cycles (standard) | ≥25 |
| Mating cycles (waterproof) | ≥5 |
| Engagernent force (single, standard) | ≤25N |
| Engagerment force (waterproof) | ≤45N |
| Disengagernent force | ≥2N |
| Retention force latch | ≥ 110N |
| Retention force primary lock | ≥ 80 N |
| Retention force secondary lock | ≥60 N |
Environmental Data | Temperature range | -40°C-+105°C |
FAKRA Coding:
FAQ:
1.Q:Can you provide samples to me?
A:Yes,we can provide samples to you and you need to pay the
shipping cost.
2.Q: Can your company accept customize?
A: Welcome OEM & ODM.
3.Q:How can l get the FAKRA connector price list?
A:Please contact us with detailed inquiry information, so we can
offer the latest price for you.
