    Ultrahigh Frequency Induction Welding Machine Serrated Single Phase 220V

    Ask Lasest Price
    Brand Name : ORD
    Model Number : UF-06AC
    Certification : CE,SGS,ISO
    Price : USD1980-2950.00
    Supply Ability : 200SET/Month Goods in Stock
    Delivery Time : 1-2 Work days
    • Product Details
    • Company Profile

    Ultrahigh Frequency Induction Welding Machine Serrated Single Phase 220V

    NEW Ultrahigh Frequency Induction welding machine of Welding Serrated Single phase 220V


    Specifications :


    ModelUHF-06AC
    Work powerSingle phase 220V 50-60HZ
    Current0.4-23A
    Max power0-6KW
    Fluctuating frequency1-2.0MHZ
    Water temperature protection point<35 ·C
    The flow rate of cooling water>0.5MPa
    Product sizemain 260X270X145MM
    heater head 120x60x105mm
    Coil pipe sizeOD 2.0mm ID1.4mm
    Net weight10.8KG


    Machine Features:

    1. It adopts the most advanced MOSFET, Siemens and particular second generation inversion technical.

    2. It could adjust the power time in heating retain and advance the quality and repeatability of heating, predigest the operation technical for worker.

    3. Easy installation, it can be used once it is connected with single phase (220V) power supply, induction coil as well as water supply pipe and rising pipe.

    4. It is small in size and light in weight, easy operation, you could learn in several minute, also it’s very safe. Output power lower then 36V, elimination of high voltage.

    5. Heating efficiency will over 95%, as compared with vacuum tube high frequency equipments, it can save the power by approximately 70%.

    6. The induction coil could free dismounting and change more convenience. Fast heating speed and it could reduce the workpiece will be oxidation and transmutation

    7 All digital control front panel system for the machine, it is more easy to compatible other machines work together by PLC.



    Application:

    A. Welding of big and small gears of hard alloy saw blade;

    B. Welding and annealing of spectacle frame and fittings;

    C. Welding of jewelleries, clock and watch;

    D. Electric industry (tin and silver soldering of fine wire, various electronic elements);

    H. Toy industry (tempering for wind spring and thin metal sheet)

    G. Welding of cutting tools as well as tempering for paper cutter and shoe knife blade;

    E. Electromechanical industry (silver and braze welding of fine metal joints as well as quench tempering for mini motor shaft);

    F. Wire material industry (annealing of wire material and sheet band);


    After-sale service:
    1. Warranty time: Within 18 months from the date of delivering, 12months from date of receiving.
    2. Within warranty all parts are free for customer, any fault caused by non artificial reason, any quality problems such as design,
    manufacture, or procedure occurs, We shall provide replacement parts after detecting the faults.
    3. If any big quality problems occurs out of the guarantee period, we will send maintenance
    technician to provide visiting service after checking with the customer and charge for a favorable price.
    5. We will provide a lifetime cost price to the buyer with the materials and spare parts used in system operation, equipment
    maintenance.
    6. The above mentioned are only basic aftersale service requirements,we will make more promises related to quality assurance and operation guarantee.
