Tungsten Carbide Nozzles are a common tool in various industrial
processes. Produced from a durable and heat-resistant material,
these nozzles direct a stream of material like gas, water, or
powder to a specific location. They are regularly found in spray
systems, heat exchangers, and chemical reactors due to their
immunity to corrosion, wear, and abrasion. Additionally, their
cost-effectiveness makes them a preferable option for many
industries.
| Grade | ISO Grade | Chemical Composition | Physical Properties | Applications |
| WC% | CO% | Density g/cm3(±0.1) | Hardness HRA(±0.5) | TRS Mpa(min) | Grain Size(μ m) |
| YG6 | K20 | 94 | 6 | 14.85-15.00 | 90.5-92 | 1800 | 1.2-1.6 | Carbide burr. |
| YG6X | K15 | 94 | 6 | 14.80-15.00 | 91.7-93 | 1600 | ＜1.0 | High wear resistance and higher, strength. Machining of chilled
alloy cast irons and refractory alloy steel or finishing of common
cast irons. |
| YG8 | K30 | 92 | 8 | 14.62-14.82 | 89.5-91 | 1900 | 1.2-1.6 | Wire drawing die and non-standard structure and mechanical
component and valve ball. |
| YG9 | K40 | 91 | 9 | 14.40-14.60 | 89-90 | 1850 | 1.2-1.6 | Flow sleeves, bushings, rings. |
| YG9C | K40 | 91 | 9 | 14.50-14.90 | 87.5-89 | 1815 | 1.2-1.6 | Nozzles, for the petroleum. |
| YG11 | K40 | 89 | 11 | 14.35 | 89 | 3200 | 1.6-2.0 | Nozzle, buttons, hemisphere, drilling teeth for the petroleum
industry. |
| YG11C | - | 89 | 11 | 14.20-14.40 | 87.5-89 | 2200 | 1.6-2.4 | Inserts for mining and high-pressure nozzles in the petroleum,
chemical, and mechanic industries. |
| YG13 | - | 87 | 13 | 14.10-14.30 | 87.5-89 | 2500 | 1.6-2.0 | Sleeves and bushings. |
| YG13C | - | 87 | 13 | 14.05-14.25 | 85.8-87.3 | 2550 | 2.4-4.0 | Alloy teeth and brazing bits. |
Source Factory Advantages
Customized, OEM Service: This refers to the ability of the source manufacturer as MINJIANG
to customize parts and components to the exact specifications of
their customers. This means that our customers can get exactly what
they need without having to pay extra for parts that are not
necessary. This can help save time and money, as well as ensure
that customers get what they want.
Competitive Price: Source manufacturers such as MINJIANG are usually able to offer
competitive prices due to their access to raw materials and their
efficient production process. This can help our customers get the
best prices and help them stay within their budget.
Short Lead Time: Source manufacturers are able to provide a short lead time due to
their efficient production process. This means that our customers
can get their parts and components delivered quickly so that their
projects can move forward without any delays.
Company Concept
Innovation is the act of introducing something fresh and new. It
can involve the introduction of new technologies, or the reworking
of existing products, services, and processes. It is a process that
requires creative thinking and risk-taking to come up with new
ideas and approaches that can add value to a business or
organization. Innovation is an ongoing cycle of experimentation and
exploration, with the potential to generate significant economic
growth. It enables organizations to remain competitive and keep up
with the ever-changing environment.
FAQ
1. Q: Do you offer customized products?
A: Yes, we often make customized products.
2. Q: Do you provide free samples?
A: We can provide free samples, but do not undertake the freight
cost.
3. Q: What payment methods do you accept?
A: We accept payment by bank transfer and Western Union.
4. Q: How is the lifespan of the nozzle?
A: The lifespan of our nozzle is quite excellent. It is specially
designed to meet the highest standards of product performance and
quality. With proper maintenance, the nozzle can last for a long
time and perform optimally.
