Marine Outfitting Equipment Manhole Cover D Type With Standard CB / T19 - 2001
Brief description:
D Type have two otion shape, one is long circular sunk type manhole cover without shield, anoth is oval sunk type manhole cover without shield.
| Item : | Manhole Hatch Covers |
| Model Number : | MOC-02 |
| Material : | Steel/Stainless steel |
| Surface : | Sandblasting treatment |
| Type : | A/B/C/D |
| Structure : | Bolt on |
| Installation : | Welded |
| Certification : | ABS, LR, BV, NK, DNV, RINA, RS, IRS,CCS |
| Standard : | CB/T19-2001 |
| Application : | Used for the ship watertight and oil tight manhole cover |
Main features:
1. Material: steel
2. Screw : Stainless Steel
3. Surface treatment: sandblasting
4. Certificate CCS , ABS , NK , etc are available
Specification:
| Nominal size | L1 | L2 | L3 | B1 | B2 | B3 | S | Fastenings | Weight | |
| mm | Dia. | Q’ty | KG | |||||||
| 450*350 | 450 | 570 | 620 | 350 | 470 | 520 | 14 | M20 | 16 | 73.1 |
| 16 | 81.6 | |||||||||
| 18 | 90.2 | |||||||||
| 600*400 | 600 | 720 | 770 | 400 | 520 | 570 | 14 | 20 | 83.6 | |
| 16 | 88.8 | |||||||||
| 18 | 94.8 | |||||||||
| 800*600 | 800 | 920 | 970 | 600 | 720 | 770 | 14 | 26 | 108.4 | |
| 18 | 120.6 | |||||||||
| 20 | 149.8 | |||||||||
| 800*400 | 800 | 930 | 980 | 400 | 530 | 580 | 14 | 24 | 89.4 | |
| 16 | 102.5 | |||||||||
| 18 | 127.8 | |||||||||
Product's photo:

|
