Free Roller Conveyor Idler Roller Conveyor China Factory Cheep
Price
Our Conveyor Roller Perfermance
Roller sealability in water
After revolving at the rate of 1450t/min for 24 hours in water,the
water inflow of the carrier roller with non-contact seal device is
not more than150g.
Roller life span
When reinforced service life of carrier roller is converted into
the actual service life,the time span is no less than 20000h.The
damage rate of carrier roller is no larger than 10%.
Roller range of application
Our product is widely used in such surrounding as underground coal
mine and that with severe open-air dust and high corrosivity.These
places include mines,power plants,steel mills,stone factory,cement
plant,coking plant,coal washing plant,saltworks,soda ash
factory,chemical fertilizer plant and wharfs.
There are numerous variables to consider when buying a conveyor system or purchasing replacement rollers.
To optimize performance and minimize operating costs it's important
to select a roller that best matches a conveyor's operating
environment.
The following items should be considered to help select a roller
that is best suited for the conveyor application.
Conveyed Items or Materials.
Size / Shape / Weight
Surface Characteristics of Materials
Operating Environment
Temperature / Humidity
Exposure to chemicals, liquids, particulate matter (dust, dirt,
etc)
Travel Speed
Roller Loading
Roller general properties
Tube size mm | Axle size mm | Tube Material | Surface treatment | The chain form |
| Φ38 | Φ12 | Stainless steel Carbon steel | Galvanization/ Hot dip galvanized/ chromeplate/ Coated rubber Coated Pu | Single chain, Double chain |
| Φ50 | Φ10,12,15,17,20 |
| Φ57 | Φ12 |
| Φ60 | Φ12,15,20 |
| Φ76 | Φ15,20 |
| Φ80 | Φ17,20 |
| Φ89 | Φ20,25 |
| Φ108 | Φ20,25 |
| Φ133 | Φ20,25 |
| Φ158 | Φ30,38 |
Product FAQ
Q: What's the lead time?
A: It takes 5-15 days for production in factory depends the total
quantity. Each sprocket can be custom made based customer side
exact parameters.
Q: How long is your company in business?
A: We shenzhen guangya wire belt company started business in 2003
and only dedicated to stainless steel wire belt production.
Q:what is the minimum order quantity?
A: 10pcs for each item
Q: can i order a sample?
A: of course, for the existing model we have, our factory would
like to offer one or two pieces sample to customer and the
air-freight charge shall be paid by customers; for customized model
making shall be consulted.
Q: can we use our own shipping agent?
A:of couse you could.
Q: can you accept OEM service?
A: yes,OEM is acceptable, pls send email to us for more detail.
Q: How do I order?
A: If you can visit our company, we can fix all technical details
quickly by live discussion. We can also send you drawing so you can
specify needed configuration. Once the wire belt structure is
confirmed, we will sign contract. We accept T/T & L/C payment.
Q: How can I verify the product?
A: Before delivery, you can send engineer to verify it by agreed
technical design.
