    RS485 Signal Surge Protector PoE Power Splitter 5V U c 6.8V U r 8.8V, 5KA 10KA

    Ask Lasest Price
    Brand Name : E-link
    Model Number : LNK-SSP
    Certification : ROHS,FCC,CE
    Price : $6.9-79
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000pcs/month
    Delivery Time : 5-12 working days
    • Product Details
    • Company Profile

    RS485 Signal Surge Protector PoE Power Splitter 5V U c 6.8V U r 8.8V, 5KA 10KA

    ROHS FCC CE PoE Power Splitter 10Mbps RS485 Signal Surge Protector


    RS485 Signal Surge Protector


    PoE Power Splitter Advantages

    ► Flow capacity, fast response

    ► Multi-level protection circuit, residual depression

    ► Use the core components of international brand products, excellent performance

    ► Take place through the special treatment to avoid signal interference

    ► Small size, easy installation


    Technical Indexes

    Model

    Parameters

    SPD-D485A
    SignalRS485
    U n Nominal voltage U n≤5V
    U c Maximum continuous operating voltage U c6.8
    ( 8/20μs ) I n Nominal discharge current (8/20μs) I n5KA
    ( 8/20μs ) I max Maximum Flow Capacity (8/20μs) I max10KA
    U r Limit voltage U r≤8.8V
    T a Response time T a≤1ns
    V stransfer rate V s10Mbps
    A E Insertion loss A E≤0.5dB
    Protected linesTwo-wire (1 pair)
    Dimension (mm)48*25*25mm



    Overview
    For intelligent control system, twisted pair of data signals over-voltage protection. Them from over-voltage sensors, operating over-voltage and electrostatic discharge caused by damage.




    Ordering Information


    ModelDescription

    LNK-SSP


    RS485 Signal Surge Protector
