    Open Loop Hall Effect Current Transducer for UPS Servo Control Systems

    Ask Lasest Price
    Brand Name : chieful
    Model Number : CS500EK1
    Price : Negotiable
    • Product Details
    • Company Profile

    Open Loop Hall Effect Current Transducer for UPS Servo Control Systems

    Open Loop Hall Effect Current Transducer for UPS Servo Control Systems
    Product Description

    open loop device based on the measuring principle of the hall effect, with a galvanic isolation between primary and secondary circuit. It provides accurate electronic measurement of DC, AC or pulsed currents.Hall current sensors are widely applicable for acquisition and feeback control of current signals in the current monitoring,inverter,solar power management,current cabinet,DC motor drive and UPS servo control systems.


    Applications


    1. VF speed regulating device

    2. Inverter / Converter

    3. UPS

    4. SMPS

    5. Electric locomotive

    6. Grid monitoring

    7. Industrial power supply (welding machine, textile machine, etc. )


    current transducer CS500EK1

    Electrical characteristics
    TypeCS050EKICS100EKICS200EKICS800EKICS400EKICS500EKI
    IPNPrimary nominal input current50100200300400500A
    IPMeasuring range of primary current0~±1000~±2000~±4000~±6000~±8000~±1000A
    VOUTNominal output voltage4±1%V
    VCSupply voltage±15(±5%)V
    ICCurrent consumptionVC=±15V <20mA
    VDInsulation voltageAC/50Hz/1min 5kV
    εLLinearity<1%FS
    VOOffset voltageTA=25℃ <±25mV
    VOMResidual voltageIPN→0 <±20mV
    VOTThermal drift of V0IP=0 TA=–25~+85℃ <±1mV/℃
    TRResponse time≤7μs
    fFrequency bandwidth(-3dB)DC~20kHz
    TAAmbient operating temperature–25~+85
    TSAmbient storage temperature–40~+100
    RLLoad resistance≥10
    StandardQ/3201CHGL02-2007

    About us

    CHIEFUL offers a wide range of current and voltage transducers in the portfolio. And our transducer can be designed according to the specific demands.The company explore foreign markets actively, our products have been sold to the United Kingdom, Germany, Denmark, France, Italy, Sweden,Turkey, Israel, South Korea, India etc.

    Exhibition

    Logistics packaging


    FAQ

    Q1: Are you a factory?
    A:We are a factory setted up more than 17 years and export more than 10years.

    Q2: When is the delivery date?
    A: 7-10 working days in general.

    Q3: Could you send me a quotation?
    A: Sure.

    Q4: How about the after service?
    A: Five years warranty.

    Q5: What about the shipping package?
    A: Anti-static package and carton.
