    Electric Data Control Heat Resistant 3 Core Cable Zero Halogen 0.6kV / 1kV Cable

    Electric Data Control Heat Resistant 3 Core Cable Zero Halogen 0.6kV / 1kV Cable


    APPLICATION

    Suitable for use in all locations where a high degree of protection against fire and fire damage has to be provided for human life and equipment. These cables may be used indoors and outdoors. Not suitable for direct burial or in water. Fire resistant to FE 180 and Circuit Integrity to E 90.


    CONSTRUCTION
    Conductor

    Solid or stranded copper conductor

    Class 1 solid copper conductor to BS EN 60228 (previously BS 6360)
    Class 2 stranded copper conductor to BS EN 60228 (previously BS 6360)


    Insulation
    Halogen free polymer Type HXI 1 according to VDE 0266


    Inner Sheath
    Halogen free compound


    Concentric Conductor
    Copper wires with a counter helix of copper tape


    Outer Sheath
    Halogen free polymer Type HM 4 according to VDE 0207


    STANDARDS
    DIN VDE 0472-814/8.83, DIN VDE 0266 DIN VDE 0276-604, DIN EN 60228 class 1 and 2 (construction), BS EN 60332-3-24 HD 308 S2 (core identification), DIN VDE 0472-814


    We supply LPCB Certified products
    The electrical and dimensional properties of this product are measured by the Technical and Quality Assurance department at the Cables laboratory. Cable performance in respect of conductor resistance, construction quality (workmanship), dimensional consistency, and other parameters are verified to published standards and approved product drawings. Conformance to RoHS (Restriction of the use of Hazardous Substances) is determined and confirmed


    CHARACTERISTICS
    Voltage Rating

    600/1000V


    Test Voltage
    4kV AC


    Operating Temperature
    -5°C to +90°C


    Short Circuit Temperature
    +250°C


    Minimum Bending Radius
    12 x overall diameter


    Outer Sheath Colour
    Black
