| Brand Name : | TL |
| Model Number : | TL-L7780-80 Linear Light |
| Certification : | ETL,CE,RoHS |
| Price : | Negotiable |
| Payment Terms : | T/T |
| Supply Ability : | 300000M per month |
| Delivery Time : | 7-15 workdays |
4ft 130lm/W LED Linear Lighting Strips Warm And White Recessed Led Strip Lighting
SMD2835
High luminous Efficiency 100lm/w
480LEDs per meter 8ft per piece
LED brand: Epistar or equivalent
100-277ACV
Warranty 3 years
Beam angle 96°
CRI≥80 lifetime 50000h
CCT/X.Y: 2700k 3000k 4000k 5000k
1, Features
High quality flexible PCB strip with ETL UL RoHS and CE certified
Aluminum 6063-T5, good heat radiation with long lifespan
Use 2835 SMD LED as light source with high brightness and large vier angle
Aluminum 6063-T5, good heat radiation with long lifespan
Support 0~10v, PWM and Resistor dimming solutions
High lighting efficiency, save energy
Linear light fixtures could be linked to be very long line
Long lifespan > 50000 Hours
Light source adopts LM-80 cerfified LED
Adopt UL class P certified power supply
Environment friendly, no UV, noinfrared, no radiation
Use high qualily LED
| Model | TL-L5276-40 | TL-L7780-40 | TL-L5276-80 | TL-L7780-80 |
| Size | 4ft | 4ft | 8ft | 8ft |
| Linkable | Non-linkable | Non-linkable | Non-linkable | Non-linkable |
| Aluminum profile | 5276 5060 5070 5075 | 7780 12575 | 5276 5060 5070 5075 | 7780 12575 |
| Lamp Cover | Optical Grade PC | Optical Grade PC | Optical Grade PC | Optical Grade PC |
| Housing | High Quality SPCC | High Quality SPCC | High Quality SPCC | High Quality SPCC |
| IP Ratings | IP20 | IP20 | IP20 | IP20 |
| LED Type | SMD2835,0.2W | SMD2835,0.2W | SMD2835,0.2W | SMD2835,0.2W |
| LED Quantity | 216pcs | 240pcs | 360pcs | 480pcs |
| CRI | >80 | >80 | >80 | >80 |
| Wattage | 40w | 40w | 80w | 80w |
| Light Efficiency | 130lm/w | 130lm/w | 98lm/w | 100lm/w |
| Lumen Output | 3120lm | 5200lm | 7800lm | 8000lm |
| Beam Angle | 96° | 96° | 96° | 96° |
| Input Current | 600mA | 1000mA | 1000mA | 1500mA |
| PF | ≥0.9 | ≥0.9 | ≥0.9 | ≥0.9 |
| Dimmable | 0-10v | 0-10v | 0-10v | 0-10v |
| THD | <20% | <20% | <20% | <20% |
| Working Voltage | 100~277VAC/50~60Hz | 100~277VAC/50~60Hz | 100~277VAC/50~60Hz | 100~277VAC/50~60Hz |
| Operation Temp | -20℃~45℃ | -20℃~45℃ | -20℃~45℃ | -20℃~45℃ |
| Package | 4pcs/ctn | 4pcs/ctn | 4pcs/ctn | 4pcs/ctn |
|
