High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment

    Buy cheap High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment from wholesalers

    Buy cheap High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment from wholesalers
    • Buy cheap High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment from wholesalers
    • Buy cheap High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment from wholesalers

    High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment

    Ask Lasest Price
    Brand Name : CF STEEL
    Model Number : 40CrNiMoA, AISI4340,39CrNiMO,40NiCRMo22,SNCM439
    Certification : ISO, Mill Certificate
    Price : USD800-900/MT
    Payment Terms : L/C, T/T
    Supply Ability : 1000t/Month
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    High Strength Alloy Steel Plate DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment

    Alloy Construction Steel DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment


    Grade:
    Alloy Steel 4140 DIN 42CrMo41.7225SCM440

    Chemical composition (%):

    GradeCSiMnP≤S≤CrMoNi≤Cu≤
    SAE 41400.38-0.430.15-0.350.75-1.000.0300.0400.80-1.100.15-0.250.250.35

    Delivery condition:

    Hot rolled or forging

    EAF or ESR material

    Black or machined surface

    Annealing HBS <217


    Available sizes:

    Round bar size: 60mm to 350mm

    Thickness: 20-300mm

    Width: 205-610mm

    Length: 2000-5800mm


    Heat Treatment:

    Quenching 850 °C, the oil cold; Tempering 560 °C, water, oil, and cold.


    Applications:


    Used in the manufacture of high strength, large cross-section forgings such as supercharger transmission gear,rear axle,hummar shank etc.


    High strength, hardenability, good toughness, low deformation in quenching, high creep strength and endurance.Used in the manufacture requirements higher than 35 crmo steel strength and conditioning section more large forgings, such as locomotive traction with the big gear, supercharger drive gear, rear axle, the load of connecting rod and a spring clip, can also be used to under 2000 m deep well of oil drill pipe joint and the fishing tool and so on.

    Changfeng Tool & Die Steel main product:


    STANDARD/GRADE of steelFlat Bar Size(mm)Round bar Size(mm)Technics
    DINAISMJISGB(China)ThicknessWidthLengthDiameterLength
    1.121SAE1050S50C50#10-450155-22002000-12000Forged, Hot Rolled
    1.2311P20PDS-33Cr2Mo10-460155-22002000-1000020-2002000-6000
    1.2738P20+Ni-3Cr2NiMnMo21-300155-22002000-800020-2002000-6000
    1.2379D2SKD10SKD1010-200155-8102000-600014-803000-6000
    1.2080D3SKD13Cr2Mo10-200155-8102000-600020-2003000-6000
    1.2083420-4Cr1310-500155-12002000-600012-3003000-6000
    1.2344H13SKD614Cr5MoSiV110-500155-16002000-600016-4003000-6000
    1.2510O1SKS39CrWMn10-200155-8102000-600020-2003000-6000
    1.7225SAE4140SCM44042CrMo10-280155-22002000-600016-4503000-6000


    About Us
    Guangzhou Changfeng Steel Co., Ltd.
    is a professional special steel company, which specializing in this line in China since 2005. Our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel, Alloy Structural Steel, Tool Steel, Stainless Steel, Carbon Steel and Forged Block.


    To ensure provide high quality products to customers, we have close cooperation with many Chinese first class special steel enterprises, including Baosteel Group, Dongbei Special Steel, Changcheng Special Steel, Hongsheng Heavy Industry, Xingcheng Special Steel and Daye Special Steel.
