    800mm Depth Outdoor Battery Cabinet

    Ask Lasest Price
    Brand Name : ESTEL
    Model Number : ET8080150AL-BA-1
    Certification : ISO9001
    Payment Terms : T/T, Paypal
    Delivery Time : 20 to 25 days
    Price : Depend on order quantity
    Supply Ability : 1000 sets per month
    • Product Details
    • Company Profile

    800mm Depth Outdoor Battery Cabinet


    Aluminum IP55 Outdoor Battery Cabinet for 4 Battery Strings With Hydrogen Release System


    ET8080150AL-BA-1


    1. Application


    ESTEL is one of the best supplier of outdoor battery cabinet in China. The aluminum outdoor battery cabinet is developed for harsh outdoor environment. The protection grade of the outdoor battery cabinet is IP55 or IP65, waterproof, and weatherproof. The outdoor cabinet include anti-vandal system to protect the batteries for thieves.


    The interior of the outdoor battery cabinet is kept cool and dry by passive air cooling, DC fans, or air conditioning.


    The outdoor battery cabinet is usually used for backup power for outdoor telecom station. The installation of the cabinet is to be bolted down to concrete or trailer.


    2. Features


    (1) The cabinet body is made from aluminum, with light weight.

    (2) The cabinet include hydrogen sensor and hydrogen release system to keep the cabinet inside safe.

    (3) Cabinet cooling: air conditioner, 220VAC or 48VDC options.

    (4) Include smoke sensor and door switch, for detecting fire and door open inside the outdoor battery cabinet.

    (5) LED lamp for illumination: 220VAC or 48VDC options.

    (6) Four battery shelves for installing 4 strings of batteries.

    (7) Weatherproof outdoor cabinet, IP55.

    (8) Vandalism resistant four point locking system.

    (9) 8 cable glands at bottom left and another 8 cable glands at bottom right.


    3. Technical Specifications


    ItemTypeTechnical Parameter
    CabinetDimensionExternal Dimension: H×W×D 1500×800×800mm
    Cabinet BaseHeight: 100mm
    Material

    Double walls

    Outer wall: aluminum

    Inner wall: steel

    Inner frame: galvanized steel

    Thermal Insulation20mm PEF
    FinishOutdoor powder coating, light grey
    Layout1 compartment, 4 battery shelves
    DoorOne front door
    LockAnti-theft four point lock, pad-lockable
    Ingress ProtectionIP55
    InstallationBolted down to concrete or trailer
    Door GasketInclude door gasket on door frame for waterproof
    EarthingCooper grounding bar
    Cable Gland8 cable glands at left of cabinet bottom and 8 cable glands at right of cabinet bottom, totally 16 cable glands PG21.
    Hydrogen ReleaseHydrogen Release SystemInclude hydrogen release system and hydrogen sensor, for discharging hydrogen inside the cabinet generated by batteries.
    SensorsSmoke DetectorDetect fire and smoke inside cabinet
    Door SwitchOpen door alarm
    Thermal ManagementCoolingAir conditioner 220VAC 50Hz, or -48VDC
    LightingLED lamp-48VDC

    4. Cabinet Dimension
