Carbon Steel Sheet China Supplier ASTM A36 Ss400 S235 S355 St37
St52 Q235B Q345b Carbon Steel Plate
Carbon steel is an iron-carbon alloy with a carbon content of
0.0218% to 2.11%. Also called carbon steel. Generally, it also
contains a small amount of silicon, manganese, sulfur, and
phosphorus. Generally, the higher the carbon content of carbon
steel, the greater the hardness and the higher the strength, but
the lower the plasticity.
(1) Carbon steel can be divided into three categories: carbon
structural steel, carbon tool steel and free-cutting structural
steel according to its purpose. Carbon structural steel is further
divided into engineering construction steel and
machine-manufactured structural steel;
(2) According to the smelting method, it can be divided into open
hearth steel and converter steel;
(3) According to the deoxidation method, it can be divided into
boiling steel (F), killed steel (Z), semi-killed steel (b) and
special killed steel (TZ);
(4) Carbon steel can be divided into low carbon steel (WC ≤ 0.25%),
medium carbon steel (WC0.25%—0.6%) and high carbon steel
(WC>0.6%) according to the carbon content;
(5) According to the quality of steel, carbon steel can be divided
into ordinary carbon steel (higher phosphorus and sulfur),
high-quality carbon steel (lower phosphorus and sulfur) and
high-quality high-quality steel (lower phosphorus and sulfur). )
And super high-quality steel.
Product name | Carbon Steel Sheet A36 S235 S275 S355 Mild Carbon Steel Iron Hot
Rolled Steel Sheet |
Technique | Hot/Cold rolled |
Surface | Black painted,galvanized,etc. |
Thickness | 2B 2D BA(bright annealed) No.1 8K HL(Hair Line) PVC |
Size | 6-400mm |
Width | 1250-2500mm, 1250-2500mm |
Length | 1000-12000mm, 1000-12000mm |
Material | A36,SS400,A283 Gr.A,.Gr.B.Gr.C,A285 Gr.A,.Gr.B.Gr.C,Q235,Q195,Q215 |
Certificate | ISO9001, CE |
Special Use | High-strength Steel Plate, High-strength Steel Plate |
Terms of payment | T/T,L/C at sight.etc. |
Standard | AISI, ASTM, BS, DIN, GB, JIS |
Type | steel plate, Boiler Vessel Plate |
Package | Waterproof pater, steel strips packed Standard export package,suit
for all kinds of transport,or as required. |
Tolerance | ±1% |
Processing Service | Bending, WELDING, Decoiling, Cutting, PUNCHING |
Application | Steel plates are widly used as boiler plate, container plate,
flange plate and ship plate, andwidly used in building
construction. |
Place of Origin | China |
Grade | Q235 |
Brand Name | LUYI |
Model Number | A36,SS400,Q235,etc. |
ASME SA 516 GR.70-55 Chemical Composition: |
Chemical Composition | Maximum C % for thickness t (mm) | | Si % | P % max | S % max |
6-12.5mm | 12.5-25mm | 25-50mm | >50mm | ≤12.5mm | >12.5mm |
ASME A516 Gr
55 | 0.18 | 0.2 | 0.22 | 0.25 | 0.55-0.98 | 0.60-1.30 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr 60 | 0.21 | 0.23 | 0.23 | 0.25 | 0.6-0.9 | 0.80-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr
65 | 0.24 | 0.26 | 0.26 | 0.28 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME A516 Gr
70 | 0.27 | 0.28 | 0.28 | 0.3 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME SA 516 GR.70-55 Mechanical Property: | ASTM A36 Hot Rolled Steel Plate |
Mechanical Property | Tensile
strength
(MPa) | Minimum
yield
strength
(MPa) | Minimum elongation (%) gauge length | Chemical Compostion | Mechanical Properties |
50mm | 200mm | Element | content | Mechanical Properties | Metric | Imperial |
ASME A516 Gr
55 | 380-515 | 205 | 27 | 23 | Carbon, C | 0.25 - 0.290 % | Tensile Strength, Ultimate | 400 - 550 MPa | 58000 - 79800 psi |
ASME A516 Gr 60 | 415 - 550 | 220 | 25 | 21 | Copper, Cu | 0.20% | Tensile Strength, Yield | 250 MPa | 36300 psi |
ASME A516 Gr
65 | 450 - 585 | 240 | 23 | 19 | Iron, Fe | 98.0% | Elongation at Break (in 200 mm) | 20.0% | 20.0% |
ASME A516 Gr
70 | 485 - 620 | 260 | 21 | 17 | Manganese, Mn | 1.03% | Elongation at Break (in 50 mm) | 23.0% | 23.0% |
| | | | | Phosphorous, P | 0.040% | Modulus of Elasticity | 200 GPa | 29000 ksi |
| | | | | Silicon, Si | 0.280% | Bulk Modulus (typical for steel) | 140 GPa | 20300 ksi |
| | | | | Sulfur, S | 0.050% | Poissons Ratio | 0.26 | 0.26 |
| | | | | | | Shear Modulus | 79.3 GPa | 11500 ksi |
products advantages
package:
Package | Standard export seaworthy package,suit for all kinds of transport,
or as required. |
Water-proof Paper + Edge protection + Wooden Pallets |
Bulk Size | Any size |
Loading Port | Tianjin, Xingang Port, Qingdao,Shanghai, Ningbo, or any China
Seaport |
Container | 1*20ft container load Max. 25 Ton, Max. length 5.8m |
1*40ft container load Max. 25 Ton, Max. Length 11.8m |
Delivery Time | 7-15 days or according to the order's quantity |
. How long will it take to execute my order?
A:Our normal lead time is 7-15 working days.,but we have many
models in stock,We will let you know the estimated lead time after
payment ASAP. Q Can I have a sample for testing?
A: Free simples, you just need pay the freight.
Q. Do you have products in stock?
A: Because we only do wholesale, usually do not have stock, we
provide fast shipping for most products, If there is any stock, we
will inform you with details. Q Do you have inspection procedures for the products? A:100% self-inspection before packing Q Can I have a visit to your factory before the order? A: Sure,welcome to visit our factory.
