Wall Mounted Outdoor Digital Signage Player Advertising Display
Waterproof
The waterproof digital signage is widely used for outdoor
advertising, wayfinds, self-services,guidance...etc
Specification of Digital Signage for Advertising
| Screen |
| szie | 32inch | 43inch | 49inch | 55inch | 65inch | 75inch | 86inch | 98inch |
Screen Panel | D-LED | D-LED | D-LED | D-LED | D-LED | D-LED | LG D-LED | BOE/ LG D-LED |
| Outdoor dedicated high-brightness LCD screen, LED direct backlight visible in sunlight; automatic photosensitive probe, adjust screen
brightness according to ambient light, save energy and reduce light
pollution. |
| Display area | 697*392mm | 941*530mm | 1074*604mm | 1209*680mm | 1428*803mm | 1650*928mm | 1895*1065mm | 2153*1214mm |
| Display ratio | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 |
| Resolution | 1920*1080 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | 3840*2160 | 3840*2160 | 3840*2160 | 3840*2160 |
| Brightness | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ | 2000cd/㎡ |
| Contrast | 1200:1 | 1200:1 | 1200:1 | 1200:1 | 1200:1 | 1200:1 | 1200:1 | 1200:1 |
| View angle | 178°(hotrizontal and vertical) |
| Protective glass |
5mm tempered glass |
6mm tempered glass |
8mm tempered glass |
| Explosion-proof glass | tempered glass, when the glass is damaged by external force, the
fragments will form obtuse-angled small particles similar to
honeycomb, which is not easy to cause serious harm to the human
body. The impact strength of tempered glass is 3 to 5 times that of
ordinary glass, and the bending strength is 3 to 5 times that of
ordinary glass. |
| Networking | Ethernet port, wifi, (4G networking is optional) |
| Touch (optional) |
| Capacitive G+G touch | touch deviation ≤ 2mm, power consumption 1.5W, free drive,
transmission mode USB2.0, better visual effect. |
| Nano touch | also known as capacitive G+F touch, touch deviation ≤ 2mm, power
consumption 1.5W, drive-free, transmission mode USB2.0 |
| Android OS |
| mainboard | CPU: RK3288 2GDDR+8G FLASH USB*4, UART*4, operating system Android
5.1 Interface USB2.0*4 RJ45* |
| Shell |
| Degree of protection |
IP55 |
| Installation method |
Wall hanging |
| Working parameters |
| Video interface |
HDMI |
| audio interface |
output |
| Brightness control |
Automatic photosensitive system |
| Temperature control |
Automatic temperature sensing Stepless speed regulation smart fan |
| Operating temperature |
-30°C to +50°C |
| Working humidity |
5% to 90% |
| Power supply | 220V, 230W | 220V, 300W | 220V,380W | 220V, 400W | 220V, 550W | 220V, 1200W | 220V, 1300W | 220V, 2180W |
| Electric control system |
| Leakage protection |
Leakage protection switch, leakage protection, overcurrent and
overvoltage protection. |
| Timing power supply |
Microcomputer timing switch, timing control machine start and stop
in different time periods. |
| Lightning protection level |
Lightning protection device, lightning protection level C, to
prevent instantaneous lightning strikes.
|
| Power supply | brand Taiwan MEAN WELL industrial-grade power supply, stable and
reliable power supply. |
| Heat dissipation system |
| temperature control | The integrated temperature control of the intelligent fan can meet
the outdoor environment of -30-+50 degrees, and the display screen
will not turn black, and the whole machine can work normally. |
| Fan | Imported axial flow fan, supporting fan speed control board,
automatic temperature sensing, automatic adjustment of fan speed,
energy saving and power saving, and prolonging the service life of
the fan. |
Advantages
1. Display module
(1) It adopts industrial-grade high-reliability modular design, which is simple and convenient to maintain, and has complete
protection measures.
(2) High resolution, high contrast, high brightness, better express
the details.
(3) Automatically eliminating afterimages, anti-ultraviolet, heat
insulation against sunlight, automatic light-sensing green
energy-saving protection for long-term use of the LCD screen.
(4) Black level extension and self-adaptation, which can enhance the depth of the image.
(5) Adopting industrial-grade LCD screen, the video image is brighter and the three-dimensional effect is
stronger.
(6) 16.7M colors, the picture is more natural, and the delicate
picture is truly free of tailing.
(7) Intelligent temperature control, environmental protection and quietness, high reliability and good stability, especially
suitable for working in harsh environments.
(8) Ultra-long life, 7*24 hours of uninterrupted work, up to 60,000 hours or more.
2. Electrical parameters
(1) The shell material is all galvanized steel cabinet, the outer
surface is imported metal paint, anti-magnetic, anti-static,
imported waterproof material, the whole machine adopts IP55 waterproof, outdoor all-weather waterproof and dustproof, anti-theft,
explosion-proof and other designs.
(2) Highly reliable electrical protection: leakage, overload, overvoltage protection, lightning protection
device, over-temperature protection, etc.
(3) Audio: Dual-channel, stereo surround power amplifier system - 8
ohms and 2×10W.
(4) The working environment temperature design standard is
+50°~-30°, and high-quality combined fans are used for cooling.
(5) Protective glass: 6-8mm tempered explosion-proof glass is used.
(6) Each system of the whole machine adopts the principle of modular design, sustainable and maintainable design.
(8) Light sensing and overheating protection system: The screen backlight adopts automatic ambient light sensing,
real-time adjustment of the screen brightness can meet the clear
image display under strong direct sunlight environment, and make
the screen clear and no energy waste at night.
