    ASTM B564 NO6625 Nickel Alloy Steel Flanges Bridas

    ASTM B564 NO6625 Nickel Alloy Steel Flanges Bridas


    YUHONG supplies ASTM B564 NO6625 Nickel Alloy Steel Flanges, this flange has many features:


    Corrosion resistant

    Accurate dimensions

    Can sustain high pressure & temperature load

    Rust proof finish

    Smooth transition from flange thickness to pipe

    Ensure excellent stress distribution


    Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Its outstanding strength and toughness is due to the addition of niobium which acts with the molybdenum to stiffen the alloy’s matrix.

    Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN. This alloy resists a wide range of severely corrosive environments and is especially resistant to pitting and crevice corrosion.


    Specification Of ASTM B564 NO6625


    TypeWN Flange,SO Flange, SW Flange, Blind Flange,Threaded Flange,etc
    StandardANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
    Size1/2″ to 48″NB
    Class / Pressure150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
    Flange Face TypeFlate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
    Flange Delivery ConditionAs Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed, Normalized and Tempered / Quenched and Tempered - BR / N / Q /T, Machined
    Flange Dimension StandardStandard - ANSI - ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, and ANSI B16.48
    Other TestingNACE MR0175, NACE TM0177, NACE TM0284, CHARPY V-NOTCH TEST, RADIOGRAPHIC EXAMINATION, XRAY, ULTRASONIC EXAMINATION, LIQUID PENETRANT, MAGNETIC PARTICLE, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc.
    Flange Value Added ServiceDraw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment
    Coating Flanges FaceZinc Plated, Yellow Transparent, Anti-rust Paint, Cold and Hot Dip Galvanized, Oil Black Paint
    Flange PackagingLoose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector


    Chemical Composition Of ASTM B564 NO6625


    ELEMENTCOMPOSITION (%)
    Carbon0.10 max
    Manganese0.50 max
    Sulfur0.015 max
    Silicon0.50 max
    Iron5 max
    Nickel58 min
    Chromium20-23

    Mechanical Properties Of ASTM B564 NO6625


    ElementDensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
    Inconel 6258.4 g/cm31350 °C (2460 °F)Psi – 1,35,000 , MPa – 930Psi – 75,000 , MPa – 5170.425

    Applications


    Fabrication Industry

    Water Pipeline Industry

    Chemical Industry

    Natural Gas Industry

    Oil And Gas Industry

    Nuclear Power Plant

    Waste Incineration Industry
