    ASME SB163 UNS N04400 Monel 400 Nickel Alloy Seamless Tube

    Ask Lasest Price
    Brand Name : YUHONG
    Model Number : ASME SB163/ UNS NO4400
    Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
    Price : 1-100000 USD
    Payment Terms : L/C, T/T
    Supply Ability : 1000 tons/month
    Delivery Time : 5-60 days
    • Product Details
    • Company Profile

    ASME SB163 UNS N04400 Monel 400 Nickel Alloy Seamless Tube

    ASME SB163 UNS N04400 Monel 400 Nickel Alloy Seamless Tube

    Monel Alloy 400 Tube is made up of a material that can operate under sub - zero temperatures. The material has excellent mechanical qualities as well. It is a 67% nickel alloy that has copper, iron, manganese, carbon and silicon in the composition.


    The Monel 400 Seamless Tube can be hot worked or cold worked to harden it. The material has high strength and high operating temperatures which allow the pipes and tubes to be used in aerospace industrial applications.

    Specification

    StandardsASTM B163/ ASME SB163, ASTM B730/ ASME SB730 UNS 4400 Tubing
    Size3.35 mm OD To 101.6 mm OD
    Inconel WERKSTOFF NR. 2.4360 Tube wall thickness0.020" –0.220", (special wall thicknesses available)
    LengthSingle Random, Double Random, Standard & Cut length Tube
    Inconel WERKSTOFF NR. 2.4360 Tubing FinishPolished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
    Form‘U’ bent, Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc
    Types of 400 Alloy TubingSeamless, ERW, EFW, Welded, Fabricated Tube / Tubing
    400 Alloy Tube EndPlain End, Beveled End, Treaded Tube
    MarkingAll ASTM B163 Monel 400 Tubing are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
    Application & uses of Monel 400 TubeOil Tube, Gas Tube, Fluid Tube, Boiler Tube, Heat exchanger Tube,
    Value Added ServiceCutting,Beveling,Threading,Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc.
    Specialize inASTM B163 Monel 400 Capillary Tube & Other Odd Size
    Monel NCF 400 Heat Exchanger & Condenser Tube
    Test CertificateManufacturer Test Certificate
    Laboratory Test Certificate from Govt. Approved Lab.
    Under Third Party Inspection
    We can also cut, thread, and groove Monel NCF 400 Tube to meet your specifications. Monel 400 Tube Dimension ANSI/ ASME B36.10, B36.19, B2.1


    Wall Thickness

    Types of Monel 400 TubeOut diameter (OD)Wall thicknessLength
    NB Sizes (in stock)1/8” ~ 8”SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160Upto 6 Meters
    Monel 400 Seamless Tube (Custom Sizes)5.0mm ~ 203.2mmAs per requirementUpto 6 Meters
    Monel 400 Welded Tube (in Stock + Custom Sizes)5.0mm ~ 1219.2mm1.0 ~ 15.0 mmUpto 6 Meters


    Chemical Composition

    GradeCMnSiSCuFeNi
    Monel 4000.30 max2.00 max0.50 max0.24 max28.0-34.0 max2.50 max63.00 max


    Mechanical Properties

    ElementDensityMelting RangeTensile StressYield Stress (0.2%Offset)Elongation
    Monel 4008.8 g/cm31350 °C (2460 °F)Psi - 80,000 , MPa - 550Psi - 35,000 , MPa - 2400.4


    Quality ASME SB163 UNS N04400 Monel 400 Nickel Alloy Seamless Tube for sale
