    CJ2B Series Gray Stainless Steel Small Piston Cylinder / Compression Cylinder

    Ask Lasest Price
    Brand Name : DOPOW
    Model Number : CJ2B Series
    Price : Negotiable
    Payment Terms : L/C, D/P, T/T, Western Union
    Supply Ability : 100000Pcs/MO
    Delivery Time : 5 working days after receiving the customers' payment
    Certification : CE ISO9001
    • Product Details
    • Company Profile

    CJ2B Series Gray Stainless Steel Small Piston Cylinder / Compression Cylinder

    CJ2B series various gray stainless steel small new compression cylinder piston cylinder new mini cylinder.


    Bore(mm)61016
    Working MediumClean Air(40µm Filteration)
    Guarantee Pressure1.05Mpa
    Max Working Pressure0.7Mpa
    Min Working Pressure0.12Mpa0.06Mpa
    Working Temperature-10~70℃
    Speed Range50~750mm/s
    Cushion TypeRubber Cushion
    Tolerance of Stroke±1.0mm

    Product Feature


    For CJ2 series Mini cylinder, the bore size 6mm, 10mm, 16mm is optional. The cylinder barrel is stainless material. The axial installation and vertical installation is optional. As to the acting type , we have double acting, single extend acting, single return acting etc. Both ends have rubber buffering. This type is widely used textile, printing, rubber, paper industries.

    Ordering Code CJ2B Series Standard Cylinder
    CJ2B 6 X 15 - R
    CJ2B→ Series Code
    Blank: basic type
    S: Single acting spring extend
    T: Single acting spring return
    6→Bore
    15→Stroke
    D→Magnet
    Blank:Without Magnet D:With Magnet
    R→Join Type
    Blank: vertical
    R: horizontal

    Packaging & Delivery

    Selling Units
    Single item
    Lead Time
    Quantity(pieces)1 - 10>10
    Est. Time(days)5To be negotiated
    Package Type

    Carton
    Single gross weight
    1.000 kg
    Single package
