    Sinotruk 45t Side Wall Cargo Heavy Duty Semi Trailers Tri Fuwa Axles

    Ask Lasest Price
    Brand Name : SCEC
    Model Number : SCECFLT45
    Certification : ISO CCC
    Price : $10000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000units per month
    Delivery Time : Within 20 work days after receive order
    • Product Details
    • Company Profile

    Sinotruk 45t Side Wall Cargo Heavy Duty Semi Trailers Tri Fuwa Axles

    Sinotruk 45t Tri-Axles Side Wall Cargo Heavy Duty Semi Trailer Fuwa Axles


    Features of Sinotruk 45t Tri-Axles Side Wall Heavy Duty Cargo Semi Trailer Fuwa Axles

    1,The fence semi-trailer is mainly suitable for medium and long-distance transportation of medium, heavy and bulk cargo, and has strong applicability.

    2,The vehicle body adopts high-quality steel, the structure of the vehicle is reasonable, the performance is reliable, the operation is simple, and the appearance is beautiful.

    3,The accessories are all products of well-known manufacturers, and they are purchased, inspected and used in strict accordance with the requirements of the quality system documents to ensure the good performance of the vehicle.

    4,The frame of the series semi-trailer is a beam-through structure, and the longitudinal beam adopts a straight type or a gooseneck type. The web height ranges from 400mm to 550mm. Manganese plates are welded. The longitudinal beams are welded by automatic submerged arc welding. The frame is shot blasted. The beams penetrate the longitudinal beams and weld the whole.

    5,The suspension adopts non-steel stamping rigid suspension (optional air suspension), which is composed of tandem steel plate springs and suspension supports; the structure is reasonable, with strong rigidity and strength, and is used to support the load to reduce the impact.

    6. Advanced software optimizes the design of products to meet the individual needs of customers.

    6, The whole vehicle adopts FEA finite element to optimize the design. According to the load requirements of the vehicle, the vehicle type is analyzed, scientifically designed, and reasonably divided.


    Technical specification of Sinotruk 45t Tri-Axles Side Wall Heavy Duty Cargo Semi Trailer Fuwa Axles

    Product nameside wall semi trailer
    Long13mWidth (m)2.55m
    Longitudinal structure10mmWABCOStringer height450-480mm
    Beam specification mm/Traction pin90#
    Tarpaulin basket1Lock8 sets
    Ladder1Load/
    SuspensionMechanicalABSWABCO
    Spare tire rack1Outriggerjost
    Toolbox1Side beam specifications14mm
    Tonnage45t
    Height (m)2.2-3.2m
    Upper Wing Board/Rising Board/Lower Wing Board8/12/14mm
    Axle brand/model/quantityFuwa, 13t
    Steel ring brand/model/quantityFactory distribution
    Tire brand/model/quantityTriangle 12R22.5
    Leaf spring brand/model/quantityBarberry 10 slices
    coloroptional
    Floor/Box3mm non-slip
