Product Description
Stainless Steel SS304 Tile Roof Hook Solar Energy System Hanger
Bolt/ Roof Hook
M8 M10 M12 M16
QBH SOLAR Adjustable Solar Panel Tilt Mount Bracket System is suitable for the flat tin roof
solar panel tilting brackets with great flexibility both for
commercial and residential roof solar system.
Patented and innovative rail design, certified mounting solution. Extra tilt angle maximizes the solar
panel output.
Solar Panel Tilt Mounting Bracketscan be used on any flat surface. Ideal for positioning solar panels
at an angle on a rooftop. Maximum tilt angles depend on the size of the panel. Lightweight aluminum
alloy material. Ideal for easy transportation and safe mounting.
Solar Roof Tilting Bracket System has great flexibility for the design and planning of
commercial or civil roof solar system.It is used for parallel
installation of commo framed
solar panels on sloping roofs.Unique aluminum extrusion guide rail,
inclined mounting parts,
various card blocks and various roof hooks can be pre-installed to
make the installation easy
and fast, saving your labor cost and installation time.The
customized length eliminates the
need for on-site welding and cutting, thus ensuring high corrosion
resistance, structural
strength and aesthetics from the factory to the installation site.
Specifications:| Place of Origin | CHINA |
|---|
| Brand Name | QBH |
|---|
| Shop | qbfastener.en.made-in-china.com |
|---|
| Certification | ISO9001 |
|---|
| Model Number | M8 M10 M12 M16 |
|---|
| Minimum Order Quantity | 900kg |
|---|
| Price | 2300-4700USD/TON |
|---|
| Packaging Details | BULK or according customer requirement |
|---|
| Delivery Time | 20days |
|---|
| Payment Terms | L/C, T/T,OA |
|---|
| Supply Ability | 300ton/month |
|---|
Material: 304
High-quality with AS/NZS 1170
Competitive price from QBH
Roof hook 304 material
Choosing an ideal solar mounting system is an important for the
installation
The objective is a solidly mounted roof hook that will last for
many years and withstand all kinds of weather
QBH company provides you the products:
Special designed for solar panel on the roof
Solar roof hook features an enormous load capacity
State-of-the-art production processes guarantee the cost-efficient
manufacturing of the roof hook
Well and high-quality control from QBH company
Easy to install
These substantial stainless steel brackets are used to secure the
mounting rails to the roof beams
These are suitable for tiled roofs only, but versions for slate
roofs and metal roofs are also available.
Product features and advantages:
1. Easy installation. The inclined mounting parts can be installed
from any position of aluminum
alloy extrusion guide rail, and pre-installed with the height of
the clamping block and hook, thus
minimizing the installation time and cost.
2. High durability: with the design concept of 20 years' service
life and 10 years' quality assurance,
all structural parts are high-strength stainless steel and anodized
aluminum alloy to ensure the
high durability of materials.
3. Withstand extreme weather. The grid solar energy inclined roof
support system is designed by
experienced engineers according to AS/NZS 1170 and other
international common standards to
withstand extreme weather conditions.The main stress components of
the system are tested in
various ways to ensure its structural bearing capacity.
4. Wide applicability. The grid solar energy inclined roof support
system is applicable to all kinds
of universal framed solar panels installed on all types of roofs in
the existing market, ranging from
small solar energy systems to large and even several megawatt
systems.
Materials and Chemical Compstition
| CHEMICAL COMPOSI(% ) |
| Type | C | Si | Mn | P | S | Ni | Cr | Mo | Cu |
| ≤ | ≤ | ≤ | ≤ | ≤ | ≥ | ≥ | ≥ | ≈ |
| 201Cu | 0.08 | 1.00 | 7.5-10 | 0.06 | 0.03 | 4.00-6.00 | 14.0-17.0 | | 2.0-3.0 |
| 201 | 0.15 | 1.00 | 8.50 | 0.06 | 0.03 | 3.50-5.50 | 16.0-18.0 | | |
| 202 | 0.15 | 1.00 | 7.5-10 | 0.06 | 0.03 | 4.00-6.00 | 17.0-19.0 | | |
| 301 | 0.15 | 1.00 | 2.00 | 0.045 | 0.03 | 5.00-8.00 | 16.0-18.0 | | |
| 302 | 0.15 | 1.00 | 2.00 | 0.045 | 0.03 | 8.00-10.0 | 17.0-19.0 | | |
XM7
(302HQ) | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 8.50-10.5 | 17.0-9.00 | | 3.0-4.0 |
| 303 | 0.15 | 1.00 | 2.00 | 0.20 | ≥0.15 | 8.00-10.0 | 17.0-19.0 | ≤0.60 | |
| 304 | 0.07 | 1.00 | 2.00 | 0.035 | 0.03 | 8.00-10.0 | 18.0-20.0 | | |
| 304HC | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 8.00-10.0 | 17.0-19.0 | | 1.0-3.0 |
| 304M | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 8.50-10.0 | 18.0-20.0 | | |
| 316 | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | |
316L
(12Ni) | 0.03 | 1.00 | 2.00 | 0.045 | 0.03 | 12.0-15.0 | 16.0-18.0 | 2.0-3.0 | |
316L
(10Ni) | 0.03 | 1.00 | 2.00 | 0.045 | 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | |
| 321 | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 9.00-13.0 | 17.0-19.0 | | Ti≤5*C% |
| 2520 | 0.08 | 1.00 | 2.00 | 0.035 | 0.03 | 19.0-22.0 | 24.0-26.0 | | |
Package & Certifications
Our Services
Professional Manufacturer: All of our Fastener are designed and
manufactured according to buyers'
specification and performance.
Quality is guaranteed: Durability testing and critical technical
design to enhance fasteners lifetime.
Cost effective: Competitive prices with professional factory supply
Perfect fastening solution with 15+ years experiences to solve your
problem: Wide range of parts selection.
Customized Ideal Fasteners: customized services according to the
samples and drawings offered.Free Samples for Standard Fastener from Jiaxing City Qunbang Hardware
We Promise:
1.High quality
2. Competitive price
3. The shortest delivery
4. The fastest response
5. The best service
FAQ
1.What's your experience like?
Our general manager has been engaged in the export of fasteners
since 2005.
Our team can provide you with professionalfasteners selling and smooth export services.
2.How about your price?
High quality products with reasonable price. Please give me a
inquire, We will quoted you a price for you
refer at once.
3. How do you control your quality?
We require the quality control department to inspect every
production link of each shipment. And we can provide you MTC and
mill certificate when the goods is finished.
4.How about your delivery time?
General speaking, if the goods is in stock, we can delivery them
with 2-5days, If the quantity is 1-2container, we can give you with
18-25days,if the quantity is more than 2 container and you are very
urgent, we can let factory priority produce
your goods.
5.What is your packing?
Our packing is 20-25kg for one carton,36 or 48pcs cartons for one
pallet. One pallets is about 900-960kg, We also can make customer's
logo on the cartons. Or we customized cartons according to
customers'
requirement.
6.What is your payment term?
We can accept T/T,LC for general order ,Paypal and Western union
for small order or samples order.
Awaiting for your kind inquiry! Thanks & best regards!
For more information: http://qbfastener.en.made-in-china.com
