| Brand Name : | CSC |
| Model Number : | ZARF ZARN Series |
| Certification : | AS9100,IATF16949,ISO9001,ISO14001 |
| Price : | Negotiation |
| Payment Terms : | Negotiation |
| Supply Ability : | Negotiation |
| Delivery Time : | Negotiation |
Needle Roller/Axial Cylindrical Roller Bearings ZARF ZARN Series
Features
ZARF ZARN series can support large radial force and axial forces from both directions. They can be assembled directly on the adjacent construction or in housing, sealing is also available.
ZARF Series
The centre ring of ZARF series is also as the outer ring of needle roller bearings. The width of inner ring should be matched with centre ring and thrust rollers. Thus, when tightening the nutlock, the bearing can get a predetermined axial preload. There are an oil groove and three oil holes on the outer ring surface. The outside surface of the two shaft locating washers is machined free from spiral marks and is suitable as the running surface for a rotary shaft seal. Also, the centre ring of this series is applied to flange assembling and with radial and axial holes for oil enter and out. The exntended shaft washer can benefit for better sealing.

ZARN Series
Centre rings of ZARN series are without assembling holes, and bearings should be assembled in housing. The extended shaft washer allows special seal carrier assembly for better sealing.

Specification
| Code | d | D | H | H1 | C | D1 | B | rsmin | r1smin | d1 | J | fixing screws | Basic Axial Load Rating | Basic Radial Load Rating | Speed Limit | Weight | ||||
| Ca | Coa | Cr | Cor | oil | grease | |||||||||||||||
| —— | mm | size | quantity | KN | KN | KN | KN | r/min | r/min | Kg | ||||||||||
| ZARF 1560 TN | 15 | 60 | 40 | 26 | 14 | 35 | 7.5 | 0.3 | 0.6 | 3.2 | 46 | M6 | 6 | 24.90 | 53.00 | 13.00 | 17.50 | 8500 | 2200 | 0.42 |
| ZARF 1762 TN | 17 | 62 | 43 | 27.5 | 14 | 38 | 9 | 0.3 | 0.6 | 3.2 | 48 | M6 | 6 | 26.00 | 57.00 | 14.00 | 19.90 | 7800 | 2100 | 0.49 |
| ZARF 2068 TN | 20 | 68 | 46 | 29 | 14 | 42 | 10 | 0.3 | 0.6 | 3.2 | 53 | M6 | 8 | 33.50 | 76.00 | 14.90 | 22.40 | 7000 | 2000 | 0.56 |
| ZARF 2575 TN | 25 | 75 | 50 | 33 | 18 | 47 | 10 | 0.3 | 0.6 | 3.2 | 58 | M6 | 8 | 35.50 | 86.00 | 22.60 | 36.00 | 6000 | 1900 | 0.78 |
| ZARF 3080 TN | 30 | 80 | 50 | 33 | 18 | 52 | 10 | 0.3 | 0.6 | 3.2 | 63 | M6 | 12 | 39.00 | 101.00 | 24.30 | 41.50 | 5500 | 1800 | 0.85 |
| ZARF 3590 TN | 35 | 90 | 54 | 35 | 18 | 60 | 11 | 0.3 | 0.6 | 3.2 | 73 | M6 | 12 | 56.00 | 148.00 | 26.00 | 47.00 | 4800 | 1700 | 1.12 |
| ZARF 40100 TN | 40 | 100 | 54 | 35 | 18 | 65 | 11 | 0.3 | 0.6 | 3.2 | 80 | M8 | 8 | 59.00 | 163.00 | 27.50 | 53.00 | 4400 | 1600 | 1.35 |
| ZARF 45105 TN | 45 | 105 | 60 | 40 | 22.5 | 70 | 11.5 | 0.3 | 0.6 | 6 | 85 | M8 | 8 | 61.00 | 177.00 | 38.00 | 74.00 | 4000 | 1500 | 1.70 |
| ZARF 50115 TN | 50 | 115 | 60 | 40 | 22.5 | 78 | 11.5 | 0.3 | 0.6 | 6 | 94 | M8 | 12 | 90.00 | 300.00 | 40.00 | 82.00 | 3600 | 1200 | 2.10 |
Details
| Packing | Paper box,Carton,Wooden Pallets,According to the requirements of clients | ||
| a) Plastic tube+ Carton+ Pallet | |||
| b) Plastic Bag+ Kraft Paper+ Carton+ Pallet | |||
| Commercial Packing | Plastic Bag+ Color Box+ Carton+ Pallet | ||
| Delivery | 3-30 days after order of Solid bicycle tire tubes | ||
FAQ:
Q: Can you print our logo on the bearings?
A: yes we can
Q: Why do we choose your company?
A: Our company has been a professional bearing manufacturer for
more than 10 year. We pay more attention to quality. For each
shipping, there are professionalists to check quality of products.
Q: What is the delivery time?
A: We have stock for most of the bearings. For small quantity, we
will arrange delivery about 1-5 days,if you need Urgently,please
confirm them with us.
Q: What is your payment term?
A: Our payment term include Alipay,T/T, Western Union, Paypal etc.
Q: Can you send bearing samples first?
A: Yes, we can send bearing samples to check quality first.
Q: What is your MOQ?
A: For common bearing model number, our MOQ is 1pc.
If you are interested in any model, please feel free to contact
with me!
|
