GB ASEM 3853 Nm3/h Gas Liquefaction Plant LIN Industrail Liquid

Gas Liquefaction Plant 3853 Nm³/h YPN-3853 Liquefaction Nitrogen Equipment

Specifications:

The followings are the standard products for the Liquefaction Nitrogen Equipment YPN series which are manufactured by our company. Regarding other particular product can be calculated and designed according to the actual requirements.

Typical Product:3853 Nm³/h YPN-3853 Liquefaction Nitrogen Plant

Output, purity and pressure

Note: 1, All pressures which are not specially defined are the gauge pressures

2, Nm³/h is defined as the volume at standard atmospheric pressure.

Description:

The low pressure nitrogen supplied by the user mixing with the refluxed gas from liquefaction plant. After being boosted through feed nitrogen booster, and mixed with feed pressure nitrogen, the mixed gas enters to the circulating nitrogen compressor to be compressed, and then it is divided into two streams: one stream flows into main heat exchanger to be cooled, after which it is fed into the high temperature expander to be expanded, and then it is out of cold box after it is re-warmed in the main heat exchanger, and returns to the inlet place of circulating nitrogen compressor. The other one stream enters into the main heat exchanger after it is boosted through the boosting ends of high temperature expander and low temperature expander, and following being cooled, it is fed to the low temperature expander to be expanded, and then it is out of cold box after being re-warmed in the main heat exchanger, and back to the inlet of circulating nitrogen compressor. The liquid nitrogen is subcooled in the liquid nitrogen subcooler, and then sent to the user’s storage tanks as product liquid nitrogen after being throttled.

Applications:

1. Welding and metal processing

2. Food and beverage

3. Chemical synthesis

4. Medical science

5. Microorganism

6. Metal production

Competitive Advantage:

1. All pressure vessels, pipelines and elements are strictly designed, fabricated and inspected in accordance with the applicable national codes. The cold boxes for air separation plants and pipelines etc. inside columns are accepted by means of strength calculation.

2. Our company has a high market share in China

3. Engineers available for commissioning overseas

4. Perfect technology R&D system

5. Low power consumption.

6. No gas loss and high yield

       Hangyang Cryogenic Liquefaction Equipment Co., Ltd. is one of the holding subsidiaries of Hangyang Co.,Ltd.(stock code:002430), it is organized on the basis of the original Small Scale of ASU Company of Hangzhou Hangyang Co,.Ltd. It is the major engineering, research and manufacturing base for small size of ASU and liquefaction plants in China, It is located in Hangyang Manufacturing Base in Lin'an Economic Development Zone, the address of sales office is No. 592, Zhongshan North Road, Hangzhou. It undertakes engineering consulting, design and manufacture, assembled construction design, installation and commissioning and supply of parts for medium and small size of ASU with its professional quality. It is the main base of design, research and manufacture for the domestic medium and small size of oxygen/nitrogen generating plants, liquid oxygen/liquid nitrogen plants, oxygen/nitrogen liquefiers, high-purity nitrogen generators, vacuum pipes and Pressure Swing Adsorption (PSA) for oxygen/nitrogen generating, etc.; Meanwhile, it is also the professional manufacturer for integrated assembly or skid type of medium size of ASU for leaving workshop by Hangyang, its abilities of design and manufacture for integrated assembly of medium size of ASU reach the leading domestic level. Our company has the independent import and export trade qualification.

      Our company possesses professional technical personnel teams of design and EPC engineering of ASU and also possesses design ability of product such as independent process calculation, project design, unit design, project EPC. The manufacture base of our company was relocated to new site in 2009. Recently, the floor area is 40.34 acres. Combinating with relocation, the imported and set-up professional manufacture production tools, moulds and equipment forms the manufacture ability for manufacture ASU whose capacity is below 30,000Nm3/h. Our company carries out the international administration concept and obtains authentication certificates of management system such as ISO9001, ISO14001 and OHSAS18001 of DET NORSKE VERITAS. Meanwhile, we obtains manufacturing license for pressure vessels manufacture D1 and D2, Zhejiang new high-tech enterprise certificate and small and medium-sized technology-based enterprise certificate, our company possesses impeccably professional manufacturing credentials for medium and small size of ASU.

     Our company sets product research, manufacture, marketing and service in one to elaborately provide general customers superiorly coordinated service on the basis of decades experience in design and manufacture and administration concept by Hangyang. Products involve aspects such as metallurgy, petrifaction, electron, machinery, building materials and aerospace. Our products are not only sold well throughout China, but also sold to the West, and our company becomes the designated supplier for several well-known gases investment companies abroad. In the cooperation with transnational large gases companies, our company absorbs and imports the advanced design concept, strict administration program, exquisite manufacturing technology so as to lead our company to develop in the direction of diversification, exquisite products and large-scale. Hangzhou Hangyang Cryogenic Liquefaction Engineering Co., Ltd. undertakes EPC works of ASU under our company.
