| Brand Name : | Haitu Steel |
| Model Number : | 201 304 316 317 321 310 309 410 420 |
| Certification : | Approved by SGS,ISO |
| Price : | negotiable |
| Payment Terms : | T/T, L/C at sight,West Union,D/P,D/A,Paypal |
| Supply Ability : | 20000 Ton/Tons per Month |
| Delivery Time : | 7-15 Days |
Stainless steel pipe is primarily used in piping systems for the transport of fluids or gases. Stainless steel pipe resists oxidation, making it a low-maintenance solution that is suitable for high temperature and chemical applications. Because it is easily cleaned and sanitized, stainless steel pipe is also desired for applications involving food, beverages and pharmaceutical applications.
304 seamless pipe has no blisters, no sand holes, no black spots, no cracks, and the weld bead is smooth. Bending, cutting, welding processing performance advantages, stable nickel content, products in line with Chinese GB, American ASTM, Japanese JIS and other specifications!
| Standards | Applicable Code No. | Steel Grade |
| ASTM | A213, A269, A268, A312, A376, A789, A790, B407, B423 | TP304/L/H/N, TP310/S/H, TP316/L/H/Ti, TP317/L, TP321/H, TP347/H, TP410/S, TP430, S31803, S32205, S32750, S32760, S32304, S31500, TP904/L, S31254, N08800, N08810, N08825 |
| ASME | SA213, SA268, SA312, SA376, SA789, SA790, SB407, SB423 | TP304/L/H/N, TP310/S/H, TP316/L/H/Ti, TP317/L, TP321/H, TP347/H, TP410/S, TP430, S31803, S32205, S32750, S32760, S32304, S31500, TP904/L, S31254, N08800, N08810, N08825 |
| JIS | JIS G3459, JIS G3463 | SUS304TB. SUS304HTB, SUS304LTB, SUS310TB, SUS310STB, SUS316TB, SUS316LTB, SUS316TiTB, SUS317TB, SUS317LTB, SUS321TB, SUS321HTB, SUS347TB, SUS347HTB |
| EN & DIN | EN 10216-5, EN 10297, DIN 17456, DIN 17458 | 1.4301, 1.4307, 1.4541, 1.4401, 1.4404, 1.4571, 1.4429, 1.4436, 1.4435, 1.4462, 1.4424, 1.4507 |


| AS 1528.1 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 12.70 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.344 |
| 15.88 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.439 |
| 19.05 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.534 |
| 25.40 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.723 |
| 25.40 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 0.949 |
| 38.10 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 1.103 |
| 50.80 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 1.455 |
| 50.80 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 1.483 |
| 63.50 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 1.961 |
| 76.20 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 2.467 |
| 101.60 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 2.973 |
| 3A ASTM A270 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 3/4 " (19.1 mm) | +/-0.005" (0.13 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 0.7218 |
| 1" (25.4 mm) | +/-0.005" (0.13 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 0.9824 |
| 1-1/4" (31.8 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 1.2412 |
| 1-1/2“ (38.1 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 1.5078 |
| 2" (50.8 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 2.0031 |
| 2-1/2" (63.5 mm) | +/-0.010" (0.25 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 2.5585 |
| 3" (76.2 mm) | +/-0.010" (0.25 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 3.0797 |
| 4" (101.6 mm) | +/-0.015" (0.38 mm) | 0.065" (1.65 mm) / 0.083" (2.11 mm) | +/- 10.0% | +1/8“ (3.18 mm) | 5.2628 |
| ISO 2037 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 21.30 | +/- 0.13 | 1.00 | +/-10.0% | +3.18 -0 | 0.506 |
| 25.00 | +/- 0.13 | 1.20 | +/-10.0% | +3.18 -0 | 0.712 |
| 25.00 | +/- 0.13 | 1.60 | +/-10.0% | +3.18 -0 | 0.933 |
| 33.70 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 0.972 |
| 33.70 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.280 |
| 38.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.100 |
| 38.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.451 |
| 40.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.160 |
| 40.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.531 |
| 51.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.490 |
| 51.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.970 |
| 63.50 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.467 |
| 70.00 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.730 |
| 76.10 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.970 |
| 88.90 | +/-0.25 | 2.00 | +/-10.0% | +3.18 -0 | 4.330 |
| 101.60 | +/-0.38 | 2.00 | +/-10.0% | +3.18 -0 | 4.983 |


|
