Safety Bus 7m Luxurious School Bus Travel Multi - Purpose 19
Passenger Seats
Application:
1, Public transportation
2, Tourism mini bus
3, City bus
4, School bus
5, Front axle:Dongfeng Dana
6, Curb Weight:6500kg
7, Oil tanks capacity:70L
Description:
Our X serires mini bus was getting popular in China from early
80's. After years of development and new designed componnets, it is
still one of the most popular minibuses in the market.
X series minibus includes 6 Meter, 6.6 meter, 7.3 meter and 7.5
meter buses, which are of luscious appearance, fluent line,
compact& comfort interior. And they can run on all rough roads.
Engine installed are all proved to be of stable & quality by
domestic market. Like Cummins engine,Yuchai engine ,Isuzu
technology engine from JMC and so on !
All vehicles are treated with cathode electrophresis,which highly
imporved the vehicle corrosion resistance.
Specification:
Model | MD6690 |
Overall Dimension | Length (mm) | 6,900 |
Width (mm) | 2,300 |
Height (mm) | 2,950 |
Wheel base (mm) | 3,650 |
Vehicle Weight | Curb (kg) | 4,500 |
Gross (kg) | 6,500 |
Seating capacity (person) | Pcs | 10~25 |
Fuel tank (L) | 80 |
Tires | Quantity | 6+1 |
Size | 7.50-16 |
Engine | Model | YC4FA115-30 |
Emission Level | Euro III |
Manufacturer | YUCHAI |
Displacement (cc) | 2982 |
Max. power (hp/rpm) | 115/2600 (85kw/2,600rpm) |
Max. torque (Nm/rpm) | 280/1600 |
Gearbox | JAC LC5T30 |
Brake | Air brake, |
Body Structure | All metal type, semi-integral body |
|
Standard Configuration |
1. Laminated front windshield & tempered rear windshield 2. Aluminum sliding side window & metal bracket rear view mirror 3. One driver door, one manual folding passenger door 4. Sunroof 5. Normal seat,2+1 layout, adjustable driver seats(back is
adjustable) 6. PVC floor 7. MP3 player, 2 speakers 8. Defrosting system for front windshield 9. Rear luggage box 10.Normal interior |
Feature
1.Appearance: Plump and stylish with integral headlamps
2.Optional: Exterior luggage rack or roof-mounted air conditioner
3.Sliding windows with a wide field of view provide access to fresh
air
4.Ergonomic design: sun visor, fan for bus driver, up-and-down
back-and-forth adjustable steering wheel, two-way shock absorber,
anti-roll bar in front suspension
5.Front & rear axles with higher carrying capacity
6.Optional exteriors: Pneumatic or manual service door
Vehicle drawing:
