2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment

    Buy cheap 2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment from wholesalers

    Buy cheap 2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment from wholesalers
    • Buy cheap 2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment from wholesalers

    2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment

    Ask Lasest Price
    Model Number : KSAP2R4
    Certification : US,CCC,UL,CUL,CCC,GS,CE,FCC,EMC,BEAB,SAA,KETI
    Delivery Time :
    Payment Terms : T/T
    Supply Ability : 1M/Month
    Price : Negotiable
    • Product Details
    • Company Profile

    2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment


    2.4W High Power Hybrid Power Supply For General Adapter, Medical and Laboratory Equipment
    Key Features of KSAP2R4

    Products highlights

    ●High Power Density

    ●EN60601 Medical Safety Approvals

    ●Optional Conformal Coating

    ●Operating temp Range ( 0℃ to 40℃)

    Industrial shock and vibration(>50G)

    ●MTBF 50K hours@25℃ (MIL-HDBK-217F)

    ●ESD: air discharging±15KV, contact discharging±8KV


    Key Applications of KSAP2R4

    It’s suitable for an extremely wide Range of applications, including:

    ●General Adapter Use medical and laboratory equipment

    Input

    ●Input Voltage : 90 to 264 VAC

    ●Frequency : 47-50/60-63hz

    ●Input current : 0.15A(Max)

    ●Inrush current : 60AMax. 240VAC

    ●Leakage current : 0.25 mA Max

    Output

    ●Over voltage protection

    ●Over current protection

    at 150% of lo and Auto-recovery

    ●Electronic short circuit protection

    ●Ripple&noise 20MHZ bandwidth:200mV

    ●Operatingtemperature 0~40℃Free convection

    ●Sea level Non-operating temperature -20~80℃

    ●Operating humidity 10-90% RH Non Condensing

    Safety standards

    ●Information technology equipment

    ●EN60601-1:1990+A1:1993+A2:1995

    Certificates and approvals

    ●Test report for EN60601

    EMI Emission

    ●Radiation Test&Conduction Test:EN 55022/FCC Part15

    ●Harmonic Test : EN 61000-3-2

    ●Flicker Test : EN 61000-3-3

    EMS immunity

    ●ESD Test:EN 61000-4-2

    ●RS Test:EN 61000-4-3

    ●EFT Test:EN 61000-4-4

    ●Surge Test:EN 61000-4-5

    ●CS Test:EN 61000-4-6

    ●DIP Test:EN 61000-4-11


    Mechanical SPEC

    Dimension L*W*H (mm) : 65*36*27

    Product tables for 2.4W

    Packing & shipping

    Down Load
