| Brand Name : | UNI-Cables |
| Model Number : | 24Core Fiber Cable |
| Certification : | ISO,TLC |
| Price : | US$0.012-1 per Meter |
| Supply Ability : | 300km per day for two core ftth drop cable |
4 6 12 24 36 48 96 core single mode indoor fiber optic distribution breakout Cables
The fiber cable could be pre-connected, is widely applied as access
building cable, interconnect between equipment, etc.
The breakout type cable contains several fibers, each with its own
jacket and all of them surrounded by one common jacket.
Tight-buffered simplex cords are surrounded with aramid yarn and
jacket, and then stranded around a central FRP member.
1 –Fiber count-------4/6/8/12/16/24/48.
2 – Characteristic of tight buffered-----OD: 0.87±0.05mm.
3 –Aramid yarn for round strength.
4 –Inner jacket-----OD: 2.0±0.05mm.
5 – Central strength member: FRP.
6 – Water barrier tape.
7-Out jacket: PVC,LSZH,Hytrel,Nylon12 or other contracted material.
Cable Structure

Features
|
Application
|

|
