AC / DC Dry Type 60KV Hipot Test Set High Voltage Testing Of Transformer

Name: AC DC Dry Type 60KV Hipot Test Set High Voltage Testing Of Transformer
Brand: Huaying
Price: 1 USD

Ask Lasest Price
Brand Name :	Huaying
Model Number :	GTB
Certification :	ISO
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	200 sets per month
Delivery Time :	7 Working Days

Add to Cart

Product Details
Company Profile

AC / DC Dry Type 60KV Hipot Test Set High Voltage Testing Of Transformer

AC / DC Dry Type 60KV Hipot Test Set High Voltage Testing Of Transformer

Overview:

Dry testing transformer series produced by our company, completely changed the old test transformer, stupid, backward status, and can produce our matching mounted on a high-voltage silicon stack can provide DC high-voltage test power supply, with a control box (Taiwan), automatic protection of meter, gap and other ancillary equipment. Especially suitable for the field test, the heavy work becomes convenient, rapid, easy and flexible, efficiency is greatly improved. Therefore, by power system and large industrial pressure test staff welcome.

Introduction:

Hipot Tester is applied in power system for insulation test of high voltage equipment.

The typical application of the HIPOT tester is as follow:

1) Power Transformer AC high voltage withstand test

2) Circuit Breaker AC high voltage withstand test

3) High voltage motors high voltage withstand test

4) Voltage/current transformer high voltage withstand test

5) High voltage power source for calibration of high voltage meter

Technical index

Model	Max output capacity KVA	Max high voltage output KV	Max current in hv circuit MA	Voltage current input of voltage booster V	Voltage current input of voltage booster A	Ratio
GTB-1.5/50	1.5	50	30	200	7.5	500
GTB -3/50	3	50	60	200	15	500
GTB-5/50	5	50	100	200	25	500
GTB-10/50	10	50	200	220/380	50/26	500
GTB -20/50	20	50	400	380	53	500
GTB -30/50	30	50	600	380	79	500
GTB -40/50	40	50	800	380	105	500
GTB -50/50	50	50	1000	380	132	500
GTB -5/100	5	100	50	200	25	1000
GTB-10/100	10	100	100	200/380	50/26	1000
GTB -20/100	20	100	200	380	53	1000
GTB -30/100	30	100	300	380	79	1000
GTB -40/100	40	100	400	380	105	1000
GTB -50/100	50	100	500	380	132	1000
GTB -100/100	100	100	100	500	263	1000
GTB -150/100	150	100	1500	500	300	100
