plastic recycling machine for PET bottle washing line and
pelletizing machine with cutting type
Main Features
1) Simple structure in linear type ,easy in installation and
maintation.
2) Adopting advanced world famous brand components in pneumatic
parts ,electric parts and operation parts.
3) High effecient productivity in plastic recycling machine of
envirenmental protection.
4) Running in a high automatization and intellectualization,no
pollution
5) Apply a random way to connect with parts ,which can directly
online as per all worshop design .
Product Application
Washing Recycling Machine Product Description:
automatic washing recycling machine is designed by company to wash
waste to reuse. This is a whole production line from
crushing,washing to drying the raw material.low cost,low
energy,easy operation is our feature. We can design the machine
according to your requirements.
plastic Washing Recycling Machine Advantages:
PET recycling machine (crushing, washing and drying) working flow:
| Waste plastic pet bottle washing recycling machine main components |
| Name: | Power: |
| Belt conveyor | 2.2kw |
| Mechenical label remover | 22kw |
| Manual separating table | 1.5kw |
| Metal detector | 0.4kw |
| Belt conveyor | 2.2kw |
| Crusher | 55kw |
| Screw conveyor | 2.2kw |
| Floating washer | 2.2kw+2.2kw+2.2kw |
| Screw conveyor | 2.2kw |
| Hot washer | 36kw |
| Screw conveyor | 2.2kw |
| High speed frication machine | 22kw |
| Screw conveyor | 2.2kw |
| Floating washer | 2.2kw+2.2kw+2.2kw |
| Screw conveyor | 2.2kw |
| Vertical dewatering machine | 11kw |
| Drying system | 36kw+7kw |
| Zig Zag air classification system | 11kw |
| Storage hopper | |
| Control cabinet |
|
- Final products has good quality. When processPET bottle, final
products humidity below 1%, impurities100ppm,PVC label content
100ppm . The whole line capacity between 300kg/h-3000kg/hour
- Parts which contact material use SUS304 stainless steel, thickness
more than 3mm, ensure long service lift time
- World famous brand components applied on the production line- SKF
bearing, Siemens contactor, Omron temperature, ABB invertor,
Siemens PLC control, etc.
- The whole production line with CE certification, ISO9001
certification
PET pelletizing line Description:
This pet flakes pelletizing line uses SJPT series parallel twin
screw extruder, is suitable for producing PET granules from clean
PET flakes.This machine is composed by SHJ parallel twin screw
extruder, die, hydraulic screen exchanger,plastic strand die head,
water cooling tank, cutter, silo.
This machine is mainly used in PET, PVC and other high viscosity
materials. with good performance, high output, less power
consumption cost per kilogram, and easy operation.
The machine can reduce less loss of the viscosity of the raw
material.
System Configuration:
Processing capacity is 100-800kg/h
The whole include:
1.Feeding Machine.
2.Extruder:38CrMoAlA with nitriding processing
3.Mould:40Cr with nitriding processing.
4.Water Channel
5.Winds drying machine
6.Pelletizer machine
7.Hopper
Advantages :
1. Increasing the operation variables and realizing the process
because of two-stage machine.
2. High effective and production capacity.
3. Good at process heat-sensitive material and devolatilization
operation, Such as PVC, XLPE.
4. Zero halogen cable, shield material, carbon black etc.
| Model | Screw Dia | L/D | Capacity(kg/h) | Main Motor(kw) |
| SJPT65 | 63 | 32-48 | 250-300 | 75 |
| SJPT75 | 72 | 32-48 | 300--400 | 90 |
| SJPT92 | 92 | 62-40 | 500-600 | 250
|
Following pictures are some sample plastic material we recycling before
Machine material processing.
Domestic famous as well as abroad nice feedback,
All parts are Stainless Steel which material touch;
Tough and heavy Q235 Steel Rack;
40 Cr Axis heat treatment;
Xi'an data motor Wouldwide famous brand solution.
Domestic famous brand, strong driving force, low energy
consumption, high economic benefits and long life during useage.
SUS 316 stainless steel, DIA219 pipe and 3mm in thichness
double separate fuction of film and scraps simultaneous
Low humidity range of 2%-3%
non stick pan.
