Stainless Steel Or Aluminium Solar Panel Exclusion Clips Easily Attached To Solar Panel Frames

Description Of The Solar Panel Exclusion Clips

Solar Panel Exclusion Clips could be easily attached to solar panel frames without damage.

This clip and wire mesh system prevents pest birds and animals from getting behind the

solar panels and damaging the electrical or mechanical systems.
The self locking washer is large and stiff, the surface black coating is durable and

the hook is plenty long enough to maintain a good grip when installing.

If special need, also could be customized:
	Item: Solar Panel Exclusion Clips J Hook Material: Stainless Steel J Hook Diameter: 2.0mm J Hook Length: 100mm Self-lock Washer Material: Stainless Steel Self-lock Washer Diameter: 38mm Self-lock Washer Thickness: 0.4mm Self-lock Washer Surface: Double Side UV Resistant Black Coating
	Item: Solar Panel Exclusion Clips J Hook Material: Aluminum J Hook Diameter: 2.5mm J Hook Length: 115mm Self-lock Washer Material: Aluminum Self-lock Washer Diameter: 38mm Self-lock Washer Thickness: 0.6mm Self-lock Washer Surface: One Side UV Resistant Black Coating

Applications Of The Solar Panel Exclusion Clips

1. Put the clip end of the fastener onto the panel edge underneath the panel. Use a clip every 18" or less. Slide as far outward as possible so the clip is seated against the lip of the panel. 2. Set the wire mesh screen in place. Make sure the fastener rod comes through the screen at an upward angle to keep pressure of the screen on the rooftop. 3. Slide the speed washer onto the shaft of the clip assembly until snug. Make adjustments to the screen as needed. Tighten the speed washer to the panel edge. 4. Cut off any excess mesh screen sticking over the top edge of the solar panel array. Cut off the clip assembly rod flush with the exterior of the speed washer. 5. Where the corners come together use two pieces of mesh screen. DO NOT try to bend the screen to go around the corner. Attach the corners together using thin bailing wire or UV rated zip ties.

Package Of The Aluminium Or Stainless Steel Solar Panel Exclusion Clips

J Hooks	1. 100 pcs per pp bag, 80 bags per carton 2. 500pcs per pp bag, 16bags per carton 3.1000pcs per pp bag, 8 bags per carton Carton size: 41 cm x 28 cm x17 cm
Self-locking Washers	1.100 pcs per pp bag, 60 bags per carton 2. 500pcs per pp bag, 12bags per carton 3.1000pcs per pp bag, 6 bags per carton Carton size: 41 cm x 28 cm x17 cm
