Rotary Drum Fertilizer Granulating Machine Chemical Fertilizer
Manufacturing Machine
Rotary Drum Fertilizer Granulating Machine is a material that can
be made into a specific shape of the molding machinery.Drum
granulator is one of the key equipment in the compound fertilizer
industry, which is suitable for the mass production of cold and hot
granulator and high, medium and low-concentration compound
fertilizers.
Rotary Drum Fertilizer Granulating Machine Feature:
- Concentrated particle size, easy to control: Compared with natural
agglomeration granulation devices (such as rotary disc granulator,
drum granulator), the particle size distribution is concentrated.
- High efficiency: it is easier to meet the requirements of
large-scale production.
- The granulation is angular and the powder rate is low: the
spherical particles have an acute angle after granulation, so the
pulverization rate is low.
Rotary Drum Fertilizer Granulating Machine Specifications
| Model | JCZL-1000 | JCZL-1200 | JCZL-1500 |
| Installation angle ° | 2-2.5 | 2-2.5 | 2-2.5 |
| Output (t/h) | 3-4 | 3-5 | 5-8 |
| Power (kw) | 75 | 90 | 110 |
| Feeding water contents (%) | 20-40 | 20-40 | 20-40 |
| Feeding materials size(mesh) | 50 | 50 | 50 |
| Overall size (mm) | 4700*2350*1600 | 4900*2550*1800 | 5500*2800*2000 |
Working process of Organic Fertilizer Production
Manure, sheep manure, cow manure, pig manure, sludge, food waste
organic fertilizer production line, processing organic fertilizer
requires two steps: pre-fermentation and treatment part and deep
processing granulation part.
Bio-organic fertilizer equipment needs fermentation turner, organic
fertilizer pulverizer, drum screening machine, horizontal mixer,
chicken manure organic fertilizer granulator, rotary dryer, cooler,
screening machine, coating machine, packaging machine, conveyors
and other equipment. Welcome to inquire!
Rotary Drum Fertilizer Granulating Machine Details
