Compact Pneumatic Air Cylinders ADNGF-80-20-P-A 554279 GTIN4052568199043

Name: Compact Pneumatic Air Cylinders ADNGF8020PA 554279 GTIN4052568199043
Brand: FESTO
Price: 1 USD

Ask Lasest Price
Brand Name :	FESTO
Model Number :	ADNGF-80-20-P-A
Price :	EXW USD150-200
Payment Terms :	T/T, Western Union, Paypal
Supply Ability :	80 pcs per month
Delivery Time :	10-15working days

Add to Cart

Product Details
Company Profile

Compact Pneumatic Air Cylinders ADNGF-80-20-P-A 554279 GTIN4052568199043

FESTO Compact cylinder ADNGF-80-20-P-A 554279 GTIN4052568199043 Pneumatic Air Cylinders

Advantage

1.Low requirements for users.

2.Large output force.

3.Strong adaptability.

Technical Data

Stroke	20 mm
Piston diameter	80mm
Based on standard	ISO 21287
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Protection against torque/guide	Guide rod with yoke
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Basic weight for 0 mm stroke	1468 g
Additional weight per 10 mm stroke	97 g
Pneumatic connection	G1/8
Note on materials	RoHS-compliant
Material cover	Aluminium Anodised
Material seals	TPE-U(PUR)
Material piston rod	High-alloy steel
Material cylinder barrel	Wrought aluminium alloy Smooth anodised

Other size as follow:

Type	Order no	Weight(g)	Price
ADNGF-80-10-P-A	554277	1565	USD150-200
ADNGF-80-15-P-A	554278	1613	USD150-200
ADNGF-80-20-P-A	554279	1662	USD150-200
ADNGF-80-25-P-A	554280	1711	USD150-200
ADNGF-80-30-P-A	554281	1759	USD150-200
ADNGF-80-40-P-A	554282	1856	USD150-200
ADNGF-80-50-P-A	554283	1953	USD150-200
ADNGF-80-60-P-A	554284	2050	USD150-200
ADNGF-80-80-P-A	554285	2244	USD150-200

Dimensions – Basic version

FESTO cylinder is safe to use, simple in system, various in models and widely used.

A wide range of products with excellent prices. Please hurry to me!
