Product Description:
LVDS 40 Interface Auto Lcd Display 1024*600 Pixels Resolution For
Top- Performance
The TFT LCD display technology used in this product ensures that
you get unparalleled color accuracy and image quality, making it
perfect for use in a wide range of applications. Whether you're
using it to display navigation information, entertainment content,
or other important data, this display will provide crystal-clear
images that are easy to read and understand.
In addition to its exceptional image quality, the Vehicle LCD
Display is also highly durable and reliable. It has a luminance of
400 nits, ensuring that it remains bright and visible even in
bright sunlight. It also has an operating temperature range of -20℃
to 70℃, ensuring that it can withstand extreme temperatures and
operate reliably in a wide range of environments.
The viewing angle of this display is TN, meaning that it has a wide
viewing angle and can be seen from multiple angles with minimal
distortion. This makes it perfect for use in vehicles where
multiple passengers may be viewing the display from different
angles.
Overall, the Vehicle LCD Display is a top-of-the-line IPS TFT
display that is perfect for use in a wide range of vehicles. With
its exceptional image quality, rugged durability, and wide viewing
angle, it is sure to provide you with the perfect display solution
for your vehicle.
Technical Parameters:
| Feature | Description |
| Model Number | 90-10126-BH1 |
| Viewing Angle(RLUD) | 70/70/60/70 |
| View Direction | 6 |
| Interface | LVDS 40 |
| Brightness(cd/m²) | 400 |
| LED Lifetime (hrs) | 20K |
| Contrast Ratio | 600 |
| Operating Temperature | -20℃ to 70℃ |
| Storage Temperature | -30℃ to 80℃ |
| Touchscreen Support | Optional touchscreen functionality (PCAP, capacitive or resistive) |
Applications:
The display is perfect for use in a wide range of applications,
including automotive, marine, and industrial environments. Whether
you need to display information about your vehicle's performance or
provide navigation instructions, this display is the perfect
solution. With a minimum order quantity of just one, you can easily
get started with this display in your project.
The display features an active area of 222.72*125.28mm and a
resolution of 1024*600 pixels, providing clear, detailed images.
The display has a luminance of 400 nits, making it easy to read
even in bright sunlight. The display has a size of 10.1 inches,
making it easy to incorporate into your project. The display is
also equipped with an LVDS 40 interface, making it easy to connect
to your system.
The Manufacturer 90-10126-BH1 Vehicle LCD Display can be used in a
variety of applications, including:
- Automotive dashboard displays
- Marine navigation systems
- Industrial control panels
- Medical monitors
- Ruggedized handheld devices
With a supply ability of 5k-20k pieces per day, the Manufacturer
90-10126-BH1 Vehicle LCD Display is the perfect solution for your
project. Order yours today and experience the quality and
performance of this IPS TFT LCD display.
Customization:
Size: From 1.77 inch to 17 inch
Imteraface: SPI ；MCU; RGB; MIPI; LVDS; EDP
Brightness: 200-1000 nits
Lifetime: 10k-50k
Touch Screen: PCAP; Capacitive touch screen, Resistive Touch screen
Wide Temperature: -40℃~85 ℃
Support and Services:
The Vehicle LCD Display product technical support and services
include:
- Troubleshooting and diagnosis of any technical issues related to
the display
- Software and firmware updates to improve performance and fix bugs
- Assistance with installation and use of the display
- Warranty and repair services for any defects or malfunctions
- Technical documentation and resources for reference and
troubleshooting
Some Classic Products in our company for reference( All products
can be tailored according to your requirements)
Size
(inch) | P/N | Resolution | Viewing
angle | Active Area
(mm) | Module Size
(mm) | Interface | OP℃ | Luminance(nit) |
| 2 | 90-02005-001 | 480*360 | IPS | 40.8*30.6 | 46.1*40.96*2.54 | RGB | -20~70 | 200-500 |
| 2 | 90-02009-001 | 240*320 | IPS | 30.6*40.8 | 36*51.6*2.45 | MCU/RGB | -20~70 | 200-500 |
| 3.5 | 90-03507-001 | 320*480 | IPS | 48.96*73.44 | 60.2*97.7*3.39 | MCU | -20~70 | 200-500 |
| 3.5 | 90-03521-BH1 | 1240*800 | IPS | 74.4*48 | 78.15*56.05*3.75 | MIPI | -20~70 | 200-500 |
| 4.3 | 90-04304-001 | 480*272 | TN | 95.04*53.86 | 105.5*67.2*3 | RGB | -20~70 | 300-600 |
| 5 | 90-05024-001 | 720*1280 | IPS | 61.78*109.82 | 65.35*118.80*1.65 | MIPI | -20~70 | 300-600 |
| 7 | 90-07018-IH2 | 1024*600 | IPS | 154.21*85.92 | 164*97*2.6 | MIPI | -20~70 | 300-600 |
| 7 | 90-07005-001 | 800*480 | TN | 154.08*85.92 | 164.9*100*5.7 | RGB | -20~70 | 300-600 |
| 8 | 90-08004-BS1 | 800*1280 | IPS | 107.64*172.22 | 114.60*184.10*2.60 | MIPI | -20~70 | 300-600 |
| 9 | 90-09001-BH1 | 1024*600 | IPS | 196.608*114.15 | 210.7*124.6*5 | LVDS | -20~70 | 300-600 |
| 9.7 | 90-09701-001 | 1024*768 | TN | 196.61*147.46 | 210.2*164.2*4.9 | LVDS | -20~70 | 300-1000 |
| 10.1 | 90-10116-IH1 | 1280*800 | IPS | 216.96*135.6 | 229.46*149.1*2.5 | LVDS | -20~70 | 300-1000 |
| 10.3 | 90-10301-BS3 | 720*1600 | IPS | 106.92*237.6 | 115*250.8*4.6 | MIPI | -20~70 | 300-1000 |
| 10.25 | 90-10251-001 | 1280*480 | IPS | 243.84*91.44 | 255.6*105.82*1.254 | LVDS | -20~70 | 300-1000 |
| 10.4 | 90-10402-001 | 1024*768 | IPS | 211.2*158.48 | 225.8*174.3*5.6 | LVDS | -20~70 | 300-1000 |
| 12.1 | 90-12101-HH1 | 1024*768 | IPS | 245.76*184.32 | 260.5*202*10.5 | LVDS | -20~70 | 300-1000 |
| 13.3 | 90-13301-BH1 | 1920*1080 | IPS | 293.8*165.2 | 305.2*178.2*2.6 | LVDS | -20~70 | 300-1000 |
| 15 | 90-15001-AH1 | 1024*768 | TN | 304.128*228.096 | 326.5*253.5*12 | LVDS | -20~70 | 300-1000 |
| 15 | 90-15002-BH1 | 1600*1200 | IPS | 304.88*228.5 | 326.58*252.98*11 | LVDS | -20~70 | 300-1000 |
| 15.6 | 90-15601-AH2 | 1920*1080 | IPS | 344.16*193.59 | 350.70*205.27*3.00 | EDP | -20~70 | 300-1000 |
| 17.3 | 90-17301-BH1 | 1920*1080 | IPS | 381.888*214.812 | 389.888*227.012*3.5 | LVDS | -20~70 | 300-1000
|
