Skid Steer Loader Attachments 72'' Angle Brooms Excavator Brooms
Sweeper Brooms
Product Description
Excavator brooms can handle a variety of materials, such as leaves,
sand, rocks, debris, snow and slush.Regardless if you have a need
for cleaning pavements, cable trenches, railway switches, tram
tracks, roofing, containers, flooding or other disaster areas from
debris, material. the Excavator brooms give you the tool to take on
the job. a skid steer loader or excavator operator may use broom to
perform the fast cleaning of streets or squares by the skid loader
and clean tunnels, walls, dry riverbeds of channels and each other
inclined or vertical surface.
Excavator brooms is designed for heavy-duty sweeping of dirt, snow,
and other unwanted material Exclusive Torsion Float Suspension
assists the operator in keeping consistent and correct bristle down
pressure, reducing excessive wear on the bristles.It is very
convenient in urban areas, with its optional sprinkling system to
reduce dust generated by the work process.Highly resistant, can
improves the engine’s performance and protects it from pressure
peaks, guaranteeing a long working life. Differently from the
excavator set up, the industrial machines configuration join a
mechanical or hydraulic angulation system of the broom.Its
adjustable stabilizing shoes keep brushes from bending when the
sweeper is set on the ground. It quickly mounts to your skid steer
or tractor loader.
Product Features
High flow options available
Easy to empty bucket
Fast wafer change time
Greaseable bearings for longer wear life
Hydraulic drive motor (no chains)
Replaceable cutting edge on bucket
longer brush life and easy replacement
Removable side shift frame available to suit most machines
Height adjustable
Product Specification:
MODEL | SSL1500 | SSL1900 | SSL2000 | SSL2200 | SSL2500 | SSL3000 |
Working width (cm) | 150 | 190 | 220 | 220 | 250 | 300 |
Full width (cm) | 180 | 216 | 253 | 253 | 280 | 300 |
Max. height (cm) | 150 | 150 | 150 | 177 | 177 | 177 |
Depth (cm) | 207 | 207 | 207 | 245 | 245 | 245 |
Bristle diameter (cm) | 70 | 70 | 70 | 90 | 120 | 120 |
Machine recommendation (operating weight) | 4-7 ton | 5 - 8 ton | 7 - 13 ton | 9 - 16 ton | 10-18ton | 10-18ton |
Empty weight | 800 kg | 900 kg | 1000 kg | 1500 kg | 1800kg | 1800kg |
Hydraulic pressure (min-max) | 160-230bar | 160-230bar | 160-230bar | 160-230bar | 160-230bar | 160-230bar |
Brush rotation (max) | 250-300 rpm | 250-300 rpm | 250-300 rpm | 250-300 rpm | 250-300 rpm | 250-300 rpm |
Water tank volume | 250 l | 250 l | 330 l | 330 l | 350l | 350l |
Q: How To Order ?
A: Step 1, please tell us what model and quantity you need;
Step 2, then we will make a PI for you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the stipulated time.
Q: When you ship my order
R: Normally container need 15-40days, sample 3-7DAYS
Q: How about the quality guarantee period?
R: One year.
Q: Do you have the certificates?
R: Yes, we have passed the CE and CCC certification.
Q: Do you offer ODM & OEM service.
R: Yes, we can custom design for specific application.
Q: When can I get the quotation?
R:We usually quote within 24 hours after we get your inquiry. If
you are urgent to get the price, please send the message on trade
management or call us directly.
Q: How can I get a sample to check your quality?
R:After price confirmed, you can require for samples to check
quality. If you need the samples, we will charge for the sample
cost. But the sample cost can be refundable when your quantity of
first order is above the MOQ
Q: What is your main market?
R:Southeast Asia, South America,Middle East.North America,EU
After-sales Service 1 year warranty for all kinds of products; If
you find any defective accessories first time, we will give you the
new parts for free to replace in the next order, as an experienced
manufacturer, you can rest assured of the quality and after-sales
service.
