PEODUCT DESCRIPTION
The working principle of the mixing truck mainly involves the
following aspects:
Force taking device. The stirring truck takes out the power of the
vehicle chassis through the force taking device, and drives the
variable pump of the hydraulic system to convert the mechanical
energy into hydraulic energy.
Hydraulic system. The variable pump in the hydraulic system
converts the mechanical energy into hydraulic energy, and then
drives the reducer by the quantitative motor, and the reducer
drives the mixing device to mix the concrete
Mixing device. The mixing device usually consists of a mixing blade
and a mixing shaft. The mixing blade is designed so that the
concrete raw materials can be fully mixed to ensure the uniformity
and stability of the concrete.
The transportation process. In the process of transporting
concrete, the mixing tank needs to keep a low speed rotation (1 to
3 revolutions per minute) to prevent concrete segregation and
maintain the uniformity of concrete.
Loading and unloading. When the mixing truck is charging, the speed
of the mixing tank is relatively fast (6 to 10 revolutions per
minute), and the concrete enters the mixing cylinder through the
charging system, and flows to the middle and lower part of the
mixing cylinder under the guidance of the spiral blade. When
unloading, the mixing truck transmits power to the mixing tank
through the engine, drives the tank to rotate, and the concrete is
discharged through the unloading hopper.
In addition, the mixer also has a cleaning function, which can
clean the mixing tank system, loading port and discharge system,
etc., to prevent concrete bonding.
Technical Parameters:
| PRODUCT NAME | Used concrete mixer truck |
| Brand | DONGFENG |
| Color | White |
| model | 7 CBM 20 Cbm 12 Cbm 10 Cbm 8 Cbm |
| Applicable Industries | Machinery Repair Shops, Manufacturing Plant, Construction works ,
Energy & Mining |
| Video outgoing-inspection | Provided |
| Machinery Test Report | Provided |
| Place of Origin | Changsha,Hunan,China |
| UNIQUE SELLING POINT | High operating efficiency |
| Other name | mobile diesel Concrete Transit concrete mixer trucks |
| Engine type | Diesel |
| Price | Negotiable |
| Total mass | Total mass 18000Kg |
| Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump |
Product picture
The company specializes in the production of all kinds of high,
medium, low pressure dry, thin oil lubrication equipment, hydraulic
components, fluid connectors, support to map customization, large
volume support logo customization, welcome overseas customers to
come to buy, excellent price, good quality.
