Hard Ferrite Magnet 2 Poles Brush DC Motor O.D42mm Series Option with integrated Gearbox Encoder and Power-off Brakes

Name: Hard Ferrite Magnet 2 Poles Brush DC Motor OD42mm Series Option with integrated Gearbox Encoder and Poweroff Brakes
Brand: SMART AUTOMATION
Price: 1 USD

Ask Lasest Price
Brand Name :	SMART AUTOMATION
Certification :	CE
Model Number :	OEM
Price :	To be negotiated
Delivery Time :	To be negotiated
Payment Terms :	D/A, T/T, L/C,D/P
Supply Ability :	10000 Piece/Pieces per Month

Add to Cart

Product Details
Company Profile

Hard Ferrite Magnet 2 Poles Brush DC Motor O.D42mm Series Option with integrated Gearbox Encoder and Power-off Brakes

O.D42mm Series

Motor Specifications

High quality ball bearing

Hard ferrite magnet, 2- poles

Protection class IP50

Insulation class: F

Certified by CE and ROHS

Options

Customized voltage, winding, shaft, mounting, and lead configurations

EMI/RFI suppression circuit; Thermal protection, high temperature Class H insulation

Motor Main Characteristics

Model	42ZYT01A	42ZYT02A	42ZYT03A	42ZYT04A	42ZYT04B	42ZYT04C
Rated Voltage	24v (option for 12v up to 60vdc)
Rated Speed (rpm)	3500	3100	3300	3350	4700	8770
Rated Torque (mNm)	38	57	65	70	100	100
No load speed (rpm)	4200	3800	4200	4000	5900	10000
Weight (g)	390	490	520	550	550	550
Motor Length (mm)	70	80	85	90	90	90
Output Power (W)	14	19	22	25	49	92
