High Quality Marine Development Titanium Plate Heat Exchanger
Plates
BAODE Plate Heat Exchanger Co., Ltd. Is a Chinese Plate Heat
Exchanger manufacturer specialized in development,Production and
global marketing of pasteurizer heat exchangers. Since the very
start in 2004 BAODE has grown to one of the leading companies in
China Plate heat exchanger market and has developed a big range of
pasteurizer heat exchangers for any task
Our main products are Brazed pasteurizer heat exchanger & Gasket
pasteurizer heat exchanger & Air cross pasteurizer heat exchanger
(Flat pasteurizer heat exchanger and frame and pasteurizer heat
exchanger, welded pasteurizer heat exchanger). Braze pasteurizer
heat exchanger include Copper brazed pasteurizer heat exchanger and
Nickel brazed pasteurizer heat exchanger.
Our mission is to help you to achieve the optimum solution with
regards to performance efficiency, payback and energy conservation,
whatever the application. This is based on a marketing orientation
concept which makes us a highly valuable partner. Our combined
experience in the pasteurizer heat exchanger industry, allow us
giving the best technical recommendation for our customers and end
users for applications such as:Refrigeration Systems that
includes,HVAC includes,Other Industrial applications.
Heat Exchanger Plates , also known as plate heat exchanger plate or
plate heat exchanger fin, is the most important component of plate
heat exchanger, and it is a part for measuring the heat transfer
efficiency of plate heat exchanger. Its quality directly affects
the heat transfer effect and overall performance of plate heat
exchangers.
Plate for plate heat exchanger.Plate heat exchanger plates are
specially used in plate heat exchangers to isolate the medium and
conduct heat exchange. They are an important part of the plate heat
exchanger.The heat exchanger plates, which make up the heat
transfer area, are clamped between the frame plates with the use of
the tightening bolts.
Baode has a wide variety of domestic plate heat exchanger plates,
more models! It can provide all common types of plate heat
exchanger plates from well-known brands at home and abroad
(including: AlfaLaval /GEA, TRANTER, SONDEX/HISAKA/APV/Thermowave
/Schmidt/FUNKE/VICARB/LHE, etc.).
Model | Area | Size A | Size B | Size C | Size D | Size E |
| M-3 | 0,032 | 431 | 125,5 | 357 | 60 | 25 |
| M6B | 0,15 | 750 | 250 | 640 | 140 | 60 |
| M6M | 0,14 | 750 | 250 | 640 | 140 | 60 |
| TS6 | 0.15/0.075 | 505 | 327 | 380 | 200 | 80 |
| M10M | 0,22 | 879 | 375 | 719 | 223 | 100 |
| M10B | 0,24 | 879 | 375 | 719 | 223 | 100 |
| Plate material | Suitable for fluid |
| Stainless steel(SUS304.316) | Purified water, river water, edible oil, mineral oil |
| TI,T-Pd | Sea water, salt water and salt chemicals |
| 20Cr,18Ni6Mo(254SMO) | Dilute sulfuric acid, dilute salt aqueous solution,inorganic
aqueous solution |
| Ni | High temperature, high concentration caustic soda |
| HASTELLOY (C276,D205,B2G) | Concentrated sulfuric acid, hydrochloric acid and carbonic acid |
