Brief look:
| Product name | wipe wall cleaning machine |
| other name | anchor /windlass winch |
| Special type for design | LBS groove |
| Height for lifting | 10-50m |
| Rope speed | 0-40m/min |
| Wire rope diameter | 3-199mm |
| Wire rope capacity | 10-500m |
| power | electric |
| Usage | clean the wall or window |
| Function | Lifting or hoisting |
| Packing | wooden case |
| Parameter | as the working usage or the rope speed |
| Payment | L/C 50% T/T |
| Delivery | 25days after confirm |
Parameter :design as usage and function designed singly
| Model | Frirst layer Pull force(T) | Drum bottom diameter | Layer | Rope capaticty(mm) | Diameter of steel cable(mm) | Model of power |
| LBSCE3-10 | 1 | 7-12 | 305 | 4 | 170 | 15 | XH2-420 D51 |
|
| LBSCE3-40 | 4 | 10-23 | 470 | 4 | 285 | 28 | XH6-2000 D240 101 |
| LBSCE3-50 | 5 | 10-25 | 600 | 4 | 350 | 30 | XH6-3000 D240101 |
| LBSCE3-108 | 8 | 15-27 | 610 | 7 | 460 | 38 | XH7-4300 D240101 |
Design characteristic:
1)Adopt the LBS groove drum design ,can make the rope working
regular on and off the drum
2)LBS design can product the rope and make the working more safely
in higher working space
3)extend the rope and drum lift about 300% than traditional design
Product specification
Custom-made (according to actual requirement)
Electric windless Winch
Electric winch is gear decelerator transmission, the winch
transforms electric energy into mechanical energy through the
motor, winch is rotor of the motor moves, outputs. Through the
brake and the reducer reduces speed to rotate the reel. The reel
winds the wire rope and passes through pulley block to make the
hook lift the load, and transforms mechanical energy into
mechanical work finishing transportation, load and unload of heavy
weights.
Product features
1. The fixing of the steel rope: adding PT screws to the drum, more
security measures than the general cable fixing method, can
effectively prevent the cable from falling off, and has good
strength and safety.
2. Drum drive mode: use star gear shaft and drive plate directly
drive drum, can easily or easily replace the cable or exchange
cable direction.
3. Electromagnetic brake: use DC electromagnetic brake, choose
advanced brake block, when power failure, electromagnetic brake
immediately automatic brake, never slide, safe and reliable.
4. Gearbox: by casting ductile iron, malleable, not easy to break,
and then by CNC computer composite machining, high precision, small
resistance; and the world's top new bearings, bearings and long
service life, low resistance, low transmission noise.
5. Special motor: E class insulation, winch special grade motor,
starting torque, inertia is small, can be used frequently for a
long time.
6. Airframe mounting: a multipurpose rack made of high quality
steel stamping, which can be used on hangers, elevators, and steel
beams
Company profile:
Our factory mainly in the service of hoisting machinery, Marine
machinery, petroleum machinery, hydraulic machinery, engineering
machinery and other industries, the main products are oil drilling
rig, workover rig, drifting machine, trailermounted pumping unit
winch (The main drum is used LBS grooved drum) and oil equipment
accessories.
