| Brand Name : | Casun |
| Model Number : | 42SHD4217-7SKQH |
| Certification : | CE,ROHS,ISO |
| Price : | $23.3-$26.3 |
| Payment Terms : | D/A, T/T, L/C, D/P |
| Supply Ability : | 40000+PCS+Month |
| Delivery Time : | 7-15 days |
Motors with encoders can achieve more complex motion control, such as precise adjustment of speed and position.
The combination of stepper motor and reducer provides high-precision motion control.
Features:

| Step Angel | 1.8 ° |
| Fram Size | 42 mm |
| Number of Phase | 2 Phase |
| Rated Current | 1.5 A |
| Holding Torque | 450 mN.m |
| Resistance | 2.2 ohm |
| Inductance | 5.0 mH |
| Rotor Inertia | 57 g-cm² |
| Motor weight | 0.4kg |
| Pulse count | 1000 |
| Connection | Bipolar |
Motor
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
Gear Box
Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°
| Motor Length | Length of Gearbox | Raio | Efficiency | ||
| 34 mm 40 mm 48 mm 60 mm | 27.2 mm | 3.71 | 90% | ||
| 5.18 | |||||
| 35 mm | 13.76 | 80% | |||
| 19.2 | |||||
| 26.8 | |||||
| 42.7 mm | 51 | 70% | |||
| 71 | |||||
| 99.5 | |||||
| 139 | |||||
