Spartan 6 FPGA XC6SLX9-2FTG256C XILINX Field Programmable Gate
Array Programmable Logic ICs
Spartan-6 FPGA Electrical Characteristics Spartan®-6 LX and LXT
FPGAs are available in various speed grades, with -3 having the
highest performance. The DC and AC electrical parameters of the
Automotive XA Spartan-6 FPGAs and Defense-grade Spartan-6Q FPGAs
devices are equivalent to the commercial specifications except
where noted. The timing characteristics of the commercial (XC) -2
speed grade industrial device are the same as for a -2 speed grade
commercial device. The -2Q and -3Q speed grades are exclusively for
the expanded (Q) temperature range. The timing characteristics are
equivalent to those shown for the -2 and -3 speed grades for the
Automotive and Defense-grade devices. Spartan-6 FPGA DC and AC
characteristics are specified for commercial (C), industrial (I),
and expanded (Q) temperature ranges. Only selected speed grades
and/or devices might be available in the industrial or expanded
temperature ranges for Automotive and Defense-grade devices.
References to device names refer to all available variations of
that part number (for example, LX75 could denote XC6SLX75,
XA6SLX75, or XQ6SLX75). The Spartan-6 FPGA -3N speed grade
designates devices that do not support MCB functionality. All
supply voltage and junction temperature specifications are
representative of worst-case conditions. The parameters included
are common to popular designs and typical applications.
Category | | |
Mfr | | |
Series | | |
Packaging | Tray | |
Part Status | | |
DigiKey Programmable | | |
Number of LABs/CLBs | | |
Number of Logic Elements/Cells | | |
Total RAM Bits | | |
Number of I/O | | |
Voltage - Supply | | |
Mounting Type | | |
Operating Temperature | | |
Package / Case | | |
Supplier Device Package | | |
Base Product Number | |
