Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters

    Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers

    Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers
    • Buy cheap Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters from wholesalers

    Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters

    Ask Lasest Price
    Brand Name : EJON
    Certification : ce
    Supply Ability : 1000 Set/Sets per Year
    Price : $9,800.00/sets 1-2 sets
    • Product Details
    • Company Profile

    Stainless Steel And Aluminum Letter Bending Machine EJON T13H CNC With Two Cutters

    Product Description

    Product Application

    T13H: 4 sets of Delta servo motors control system.

    1. Aluminum profile frame and chrome-faced.

    2. The specially designed extra long alternate feeding mechanism.

    3. Double ball screws drive make it more powerful, more fast and higher precision.The mechanical hand feeding design,continuously feeding by the two clamps, can avoid feeding slipping and improve feeding precision.

    It is the first choice for producing the word shell of LED, aluminium letters, stainless steel characters, punching words and resin words, etc.

    SPECIFICATIONS
    Feeding system
    Double ball-screw alternate feeding device
    Slotting System
    Plane cutter and alloy milling cutter system
    Bending System
    Double blade alternate bending system
    Suitable Material
    Stainless steel, Galvanized steel, Aluminum plate, Aluminium profile
    Material Height
    Stainless steel,Galvanized steel,Aluminum plate:20~130mm/
    Aluminum profile:20-100mm
    Material Thickness
    0.4-1.2mm
    Control System
    4 axis servo control system
    Min. Bending Angle
    R6
    File Format
    Dxf.Plt.Ai
    Power
    AC220V,50Hz,3.0Kw
    Air Supply
    0.6m3/Min
    Total Weight
    550Kg

    Main Features

    1) The special designed extended bending mechanism can effectively ensure the long process path forming angle.

    2) The 4-axis control system of feeding, slotting, slotting height and bending has improved processing efficiency and stability.

    3) The main hardware of the machine is monobloc casting (bending mechanism, clamping mechanism and encoder, etc.) which ensure the strong stability.

    4) 4 sets of servo control system.

    Detailed Images

    Feeding system

    The mechanical hand feeding design, continuously feeding by the two clamps which can avoid feeding slipping and improve feeding precision.

    Cutting system

    Wheel cutter and plane cutter for aluminum profile and stainless steel materials

    Bending system

    Alternative double benders bending system, fast bending speed, high accuracy.

    Punching holes

    Making holes automatically to make the producing sign letters easier.

    Supporting Facility
    Our Service

    Pre-Sales Service

    * Inquiry and consulting support.

    * Sample testing support.

    * View our Factory.

    After-Sales Service

    * Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.

    Packing & Delivery
    Packaging
    Size
    1600(L) * 750 (W) * 1620(D)
    Weight
    550KG
    Packaging Details
    1.The normal package is wooden box(Size: L*W*H).
    2. Customers special request.
    Packaging
    Size
    660(L) * 660(W) * 1110 (D)
    Weight
    45KG
    Packaging Details
    1.The normal package is wooden box(Size: L*W*H).

    2. Customers special request.
