2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower

    Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers

    Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers
    • Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers
    • Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers
    • Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers
    • Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers
    • Buy cheap 2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower from wholesalers

    2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower

    Ask Lasest Price
    Brand Name : Shuangyi
    Supply Ability : 100 Piece/Pieces per Month
    Price : $8,500.00/pieces 1-2 pieces
    • Product Details
    • Company Profile

    2820mm x 2900mm FRP Shell Low Noise Anti Corrosive Round Counter Flow Cooling Tower


    100Ton Low Noise FRP Counter-Current Cooling Tower


    Production description:


    Excellent performance


    The comprehensive optimization design causes the YDFH cooling tower to allocate the water, the air flow field to be even, the overall performance achieves best.


    Quality Excellence

    Selects the high quality patented filler, the target type sprayer to allocate water, the cooling tower special-purpose use all seal up electrical motor, the width leaf blade special-purpose air blower and the optimization design belt transmission system; The shell uses the FRP compound materials, the color is bright, surface bright and clean, anti-aging, non-fading, causes the cooling tower service long time keep new.

    Environmental protection and energy conservation

    Used the pour water filler with water collector, will drift control water loss in 0.1 percent below, the distribute water sink with cover to prevent contamination of the water cycle; it select wide blades, low-speed fan, to reduce the outlet of the dynamic pressure Loss of energy conservation effectively and environmental protection.


    Ultra low noise

    The speed reducer uses imported bearing, the air blower with wide leaf blade, low wind speed, enables the air blower noise to be under the active control; Uses the noise elimination flow divider, the sprayer distribute water and the unique design filler, will reduce the noise of spray water fall lowly.

    Small size, light weight

    After Solid Edge the CAD optimization design, the cooling tower maximum limit reduces the area; the tower body structure uses the hot dipping zinc steel skeleton and the FRP compound materials, reduced the tower body weight quantity.


    The data parameters of the cooling tower


    Model

    Cooling water volume m3/h

    Rated power

    kW

    External dimensions(mm)

    Air blower diameter mm

    inflow water pressure 104Pa

    Dead weight

    kg

    Rotation Weight

    kg

    B

    H

    YDFN-100

    100

    3.0

    2600

    4170

    1800

    6.0

    1320

    2510

    YDFN-125

    125

    4.0

    2600

    4170

    1800

    6.0

    1470

    2970

    YDFN-150

    150

    4.0

    3000

    4470

    2400

    6.0

    1750

    3550

    YDFN-175

    175

    5.5

    3000

    4470

    2400

    6.0

    1880

    3950

    YDFN-200

    200

    5.5

    3600

    4710

    2800

    6.4

    2160

    4560

    YDFN-250

    250

    7.5

    3600

    4710

    2800

    6.4

    2450

    5100

    YDFN-300

    300

    7.5

    4300

    5400

    3400

    6.4

    2980

    6580

    YDFN-350

    350

    11.0

    4300

    5400

    3400

    6.4

    3440

    7550

    YDFN-400

    400

    11.0

    4800

    5740

    3800

    6.4

    4100

    8920

    YDFN-500

    500

    15.0

    5300

    6030

    3800

    6.8

    4970

    11450

    YDFN-600

    600

    15.0

    6000

    6420

    4200

    6.8

    6570

    13700

    YDFN-750

    750

    22.0

    6800

    7110

    4200

    6.8

    8500

    17580

    YDFN-900

    900

    30.0

    7300

    7690

    4700

    7.0

    9840

    19860

    YDFN-1000

    1000

    30.0

    7800

    8100

    4700

    7.0

    11550

    24100


    Pictures Show




    Exhibition

    Company Information

    Jinan Shuangyi Environment Engineering Co., Ltd. (Shuangyi) integrates science and technology, engineering and trade together. Our main products are cooling towers, water tanks, air ventilators, ventilator pipelines, fireproofing valves, fume extract valves, lab facilities and composite materials.



    Contact info:

    Whatsapp: +86 13255693170
    Wechat:frpwatertank
    Skype:cnfrp369
