    STM32L011F3U3TR 32-Bit Single-Core 32MHz ARM Cortex-M0+ Microcontroller IC

    Ask Lasest Price
    Brand Name : Original Factory
    Model Number : STM32L011F3U3TR
    Certification : Lead free / RoHS Compliant
    Price : Contact for Sample
    Payment Terms : T/T, L/C, Western Union
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    STM32L011F3U3TR 32-Bit Single-Core 32MHz ARM Cortex-M0+ Microcontroller IC

    STM32L011F3U3TR 32-Bit Single-Core 32MHz ARM Cortex-M0+ Microcontroller IC


    Product Description Of STM32L011F3U3TR

    STM32L011F3U3TR incorporates the high-performance Arm® Cortex®-M0+ 32-bit RISC core operating at a 32 MHz frequency, high-speed embedded memories (up to 16 Kbytes of Flash program memory, 512 bytes of data EEPROM and 2 Kbytes of RAM) plus an extensive range of enhanced I/Os and peripherals.


    Specification Of STM32L011F3U3TR

    Part Number

    STM32L011F3U3TR

    Number of I/O

    16

    Program Memory Size

    8KB (8K x 8)

    Program Memory Type

    FLASH

    EEPROM Size

    512 x 8

    RAM Size

    2K x 8

    Voltage - Supply (Vcc/Vdd)

    1.65V ~ 3.6V

    Data Converters

    A/D 7x12b

    Oscillator Type

    Internal

    Operating Temperature

    -40°C ~ 125°C (TA)

    Mounting Type

    Surface Mount


    Features Of STM32L011F3U3TR

    • 1.65 V to 3.6 V power supply

    • -40 to 125 °C temperature range

    • 0.23 µA Standby mode (2 wakeup pins)

    • 0.29 µA Stop mode (16 wakeup lines)

    • 0.54 µA Stop mode + RTC + 2 KB RAMretention

    • Down to 76 µA/MHz in Run mode

    • 5 µs wakeup time (from Flash memory)

    • 41 µA 12-bit ADC conversion at 10 ksps

    • Ultra-safe, low-power BOR (brownout reset) with 5 selectable thresholds

    • Ultralow power POR/PDR

    • Programmable voltage detector (PVD)

    • 0 to 32 MHz external clock

    • 32 kHz oscillator for RTC with calibration

    • High speed internal 16 MHz factory-trimmed RC (+/- 1%)

    • Internal low-power 37 kHz RC

    • Internal multispeed low-power 65 kHz to 4.2 MHz RC– PLL for CPU clock

    • Up to 16 KB Flash memory with ECC

    • 2 KB RAM

    • 512 B of data EEPROM with ECC

    • 20-byte backup register

    • Sector protection against R/W operation
