    High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass

    Ask Lasest Price
    Brand Name : Shine Abrasives
    Model Number : 1A1R
    Certification : ISO
    Price : FOB
    Payment Terms : L/C, T/T
    Supply Ability : 1000 pcs in one week
    Delivery Time : 5 work days
    • Product Details
    • Company Profile

    High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass

    1A1R resin bond diamond high precision cutting slotting grinding wheel for ceramic glass for induction cooker

    1A1R Diamond Cutting Wheel

    The 1A1R Special combines a steel core with the 1/4″ diamond or CBN section. The result is a highly rigid wheel primarily used for deeper cutting applications, which require additional wheel exposure. This wheel is used on standard surface grinders, OD grinders and machining centers. The 1A1R Special is available in 4″, 5″, 6″, 7″ and 8″ diameters. The thickness ranges from .032″ to .375″ in increments of .001″.
    D(mm)
    T(mm)
    U(mm)
    H(mm)
    X(mm)
    4” /100
    1
    0.8
    31.75
    10
    5”/ 125
    1
    0.8
    31.75
    10
    6”/ 150
    0.8 / 1
    0.6 / 0.8
    31.75
    10
    8”/ 200
    1
    0.8
    31.75
    10
    12”/ 300
    1 / 1.5
    1.3
    31.75
    10
    16”/ 400
    2
    1.8
    31.75
    10

    Diamond cut off wheels
    For cutting carbide, glass, ceramic, sillicon, quartz, glass fiber plastics (GRP), graphite, QFN and ultra hard steel, etc
    CBN cut off wheels
    For cutting hardened steel, cast iron, HSS, magnetic materials, bearing steel and mould steel, etc
